8 Channels 5V100mA Battery Tester

Name: 8 Channels 5V100mA Battery Tester
Brand: Shenzhen TICO Technology Co.,Ltd.
SKU: STC-4008Q-5V100mA
Price: 2,499.30 USD
Availability: InStock

Brand Name:	TICO
Model Number:	STC-4008Q-5V100mA
MOQ:	1 Set
Price:	Negotiable
Delivery Time:	In Stock
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Product Name:

5V100mA Battery Tester

Model:

STC-4008Q-5V100mA

Channel:

Dimension:

483*310*43

Packaging Details:

Standard Expert Wooden Packing, Size: L232 * W165 * H320mm

Supply Ability:

20 sets per month

Highlight:

Pouch Cell Assembly Equipment

Manual Pouch Cell Assembly Equipment

Coin Cell Hydraulic Crimping Machine

Product Description

8 Channels 5V100mA Battery Tester

Brief Introduction

It is specially designed for small battery and electrode material R&D testing. It covers 5V voltage range and up to 100mA current range with minimum output as low as -5A, and 4 auto-switch ranges meet full current testing needs.

Key Features

● Each channel is control independently.

● Double range.

● High testing efficiency.

● Widely application.

● Compact size.

Technical Details

Input power		AC 220V ±10% / 50Hz
Resolution		AD: 24bit; DA: 16bit
Input resistance		≥ 1GΩ
Overall system efficiency		Not
Input power		40W
Noise		<55dB (measured at 1m)
Parallel ability		Channel parallelism is not supported
IP level		IP20
Channels feature		Independent pairs of closed loop for constant current source and constant voltage source
Channels control mode		Independent control
Data acquisition		Four-wire connection
Voltage	Output range	10mV~5V
	Minimum discharge voltage	-5V
	Accuracy	± 0.01% of FS
	Stability	± 0.02% of FS
Current	Output range	Range 1: 0.1mA Range 2: 1mA Range 3: 10mA Range 4: 100mA
	CV cut-off current	Range 1: 0.1μA Range 2: 1μA Range 3: 10μA Range 4: 0.1mA
	Accuracy	± 0.01% of FS
	Stability	± 0.02% of FS
	Minimum output current	0.2μA
Power	Per channel output power	0.5W
	Stability	0.04% of FS
	Accuracy	±0.02% of FS
Time	Current response time	≤1ms (10% ~ 90% of FS)
	Current conversion time	≤40ms (-90% ~ 90% of FS)
	Working step time	≤(365*24)h/step Time format-00:00:00.000(h, m, s, ms)
	Frequency	10Hz (Minimum time interval: 100ms)
Working mode	Charge/Discharge modes	CC,CV,CCCV,CP, Pulse,etc
	Cut-off condition	Voltage, current, time, capacity,energy,etc
	DCIR	supported
	Pulse charge/discharge mode	Current, power
	Min pulse	500ms
	Pulse counts	Up to 32
	Chg and Dchg switch	unsupported
	Cut-off condition	Voltage, ΔTime
Cycle	Max cycles	1~65535 times
	Max steps	≤255
	Cycle nest	<10
Protection mode	Software protection	Safety protection conditions can be set, including: voltage lower limit, voltage upper limit, current lower limit, current upper limit, etc.
	Hardware protection	Anti-reverse connection, over-voltage, over-current, over-temperature, etc.
Communication and computer configuration requirements	CPU	Pentium dual-core or above, frequency 4G or above
	Computer memory	Recommended 16G or above
	Connection for PC	TCP/IP
	Disk drive config	Min. 500GB
	PC operating system	Windows 7 and above
	Database	MySQL
	Data export format	EXCEL,TXT,GRAPH,PDF,CSV
	Communication expansion(optional)	Support CAN, RS485 communication and BMS communication, with DBC configuration function
Operation and storage environment requirement	Operating temperature	0℃~40℃ (When the temperature is 25±10℃, the accuracy offset caused by temperature is less than 50ppm /℃)
	Storage temperature	-10℃~50℃
	Operating humidity	≤70% RH (no moisture condensation)
	Storage humidity	≤80% RH (no moisture condensation)
Fixture specifications and equipment dimensions
Clamp types		Optional (to be clearly marked during order confirmation)
Clamps pictures		For reference only
Channel		8
Dimension WDH(mm)		1U(19"), 48331043

Warranty

1 year warranty with lifetime support. Man-made damage is not covered.
