Product Details:
|
| Product Name: | One Station Glove Box | Feature: | Internet Of Things |
|---|---|---|---|
| Application: | Laboratory For Lithium-ion Battery Fabrication | Leakage Rate Of Box: | 0.05 Vol％/h |
| Structure: | One Section Workstation | Applicable Industry: | Lithium Battery, Physical Chemistry, OLED&PLED, Organometallic, Fine Chemicals, Etc |
| High Light: | Single Station Vacuum Glovebox,R&D Vacuum Glovebox,Battery glove box vacuum chamber |
||
Single Station Vacuum Glovebox for Lab Battery R&D
Brief Introduction
STC-VGB-11 is an internet of things vacuum glovebox, centralized equipment management intelligent analysis & early warning of equipment status, the abnormal alarm message is actively pushed, remote fault diagnosis and online debugging. H2O & O2<1ppm. It is widely used for Lithium Battery, Physical Chemistry, OLED&PLED, Organometallic, Solar Cell, Semi-Conductor, Catalyst, Material Handling, Fine Chemicals, Polymeric Materials, Powder Metallurgy, Special Welding, Special Lamps, Nuclear Technology, Pharmaceutical etc.
Features
● Intelligent analysis & early warning of equipment status, the abnormal alarm message is actively pushed, remote fault diagnosis and online debugging
● H2O & O2<1ppm
● Low leak rate
● PLC control
● Wide application
● World famous brand components are used.
Main Data
1) H2O & O2: <1ppm
2) Leakage rate of box: 0.05 vol％/h
Technical Parameter
| Glovebox House | |
| House | Material: Stainless steel type 304, thickness 3mm |
| Inside surface: Brushed finish | |
| Outside surface: Enameled, White | |
| Inside dimension: L1220 * W750 * H900mm | |
| Window | Safety glass with thin film, thickness 8mm |
| Glove port | POM, O ring sealed, 2 ports |
| Gloves |
1 pair, Butyl, thickness 0.4mm, Dia. 8 inch x length 32 inch |
| Dust filter | 0.3 micron,1 gas inlet and 1 gas outlet filter included |
| Shelves | 2 layers shelves inside, height adjustable |
| Light | LED light front mounted |
| Feedthrough |
DN 40 KF: several pieces Electrical feedthrough: 1 electrical plug for inside |
| Vacuum Chamber | |
| Big Antechamber | |
| Chamber |
Inside dimension: φ360mm x L600mm |
| Material: Stainless steel type 304 | |
| Surface: Brushed finish inside and Painted white outside | |
| Accessories |
Door: double door, anodized aluminium Material: Stainless steel type 304 Thickness: 10mm |
| Manometer: Analog display | |
| Control | Manual |
| Mini Antechamber | |
| Chamber | Inside dimension: φ150mm x L300mm |
| Material: Stainless steel type 304 | |
| Surface: Brushed finish inside and Painted white outside | |
| Accessories |
Door: double door, anodized aluminium Material: Stainless steel type 304 Thickness: 10mm |
| Manometer:Analog display | |
| Manual | |
| Control | Manual |
| Gas Purification | |
| Purifier | Function: Removal of H2O and O2 |
| Container material: Stainless steel type 304 | |
|
Absorber unit: Copper catalyst: 5Kg Molecular sieve: 5 Kg |
|
|
Capacity of purifying: Removal of 60L O2, Removal of 2Kg H2O |
|
| H2O and O2: less than 1ppm | |
| Gas Circulation | Working gas: Nitrogen, Argon and Helium |
| Blower: 90m3/h | |
| Regeneration | Operation: Auto. PLC controlled Regeneration. |
| Regeneration gas: working gas / H2 mixture (H2: 5-10%) | |
| Pump | Type: 12m3 /h Rotary vane pump, Oil mist Angle valves, Gas ballast control. |
| Valves | Main valves: DN 40 KF electro-pneum. Angle valves |
| Controlling System | |
| Function | Includes self-diagnosis, electric failure and restart, pressure controlling and self-adapt, circulation controlling, code protection, union controlling adopts, SIEMENS PLC touch screen etc. |
| Pressure controlling | The pressure in the box is controlled by PLC, the pressure can be settled between +/- 10mbar, while beyond +/- 12mbar the system will automatically protect itself. |
| Foot switch | Controlling the pressure, easy to raise or depress the pressure |
| Accessories | |
| Moisture Analyzer | Measuring Range: 0~500ppm, display by PLC |
| Oxygen Analyzer | 0~1000ppm, display by PLC |
| Internet of things system | |
| Function |
|
Warranty
1 year warranty with lifetime support. Man-made damage is not covered.
FAQ
1. Are you a manufacturer?
A: Yes, our factory is located in Shenzhen, China.
We have more than 10 year experience for manufacturing battery lab research equipment. We own a professional R&D department.
2. Do you accept customized product?
A: Yes. Most of our products can be customized to meet different requirements.
3. Will you provide test video before dispatch?
A: Yes, we take test video for every equipment before dispatch, which will display how to use it.
4. Can you offer overseas installation service?
A: Yes, we can dispatch professional engineer for on-site installation service.
