150ml Benchtop Vacuum Mixing Machine with Single Shaft

Brand Name:	TICO
Model Number:	STC-EBJ-150
MOQ:	1 Set
Price:	Negotiable
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen, China

Product Name:

Vacuum Mixer

Mixing Container:

150ml As Standard, Other Size Is Optional

Mixing Container Material:

Stainless Steel

Mixing Paddle:

Single Shaft

Vacuum Pump:

Built-in Type

Mixing Speed:

1400rpm

Packaging Details:

Wood Packing

Supply Ability:

30 sets per month

Highlight:

Laboratory Vacuum Mixing Machine

150ml Vacuum Mixing Machine

150ml Single Shaft Mixing Machine

Product Description

150ml Benchtop Vacuum Mixing Machine with Single Shaft

Brief Introduction

This product is a bench-top vacuum mixer that suitable for the mixing process of battery cathode and anode slurries, powdered materials and ceramics. By conducting the mixing process under vacuum conditions, it effectively eliminates gas bubbles, ensuring optimal mixing and enhanced material properties. It has a 150ml mixing container, other volume of mixing container is optional.

Key Features

● Built-in vacuum pump for space saving purpose.

● Volume of mixing container can be optional.

● Mixing time is adjustable.

● Mixing speed is adjustable according to users actual requirement.

● Wide application.

Technical Parameter

Model	STC-EBJ-150
Voltage	AC220V±10%, 50Hz
Power	150W
Mixing container	Single mixing paddle: 150ml SS304 mixing container 50, 100, 150, 250ml mixing container can be customized
Mixing rotation speed	0~1400 rpm adjustable
Mixing time	0~9999 min settable
Speed regulation method	Continuously variable
Vacuum degree	≤ -80KPa
Dimension	L245 * W260 * H490mm
Weight	15kg

Warranty

1 year warranty with lifetime support. Man-made damage is not covered.

FAQ

1. Are you a manufacturer?

A: Yes, our factory is located in Shenzhen, China.
We have more than 10 year experience for manufacturing battery lab research equipment. We own a professional R&D department.

2. Do you accept customized product?

A: Yes. Most of our products can be customized to meet different requirements.

3. Will you provide test video before dispatch?

A: Yes, we take test video for every equipment before dispatch, which will display how to use it.

4. Can you offer overseas installation service?

A: Yes, we can dispatch professional engineer for on-site installation service.
