Pouch Cell Battery Electrode Rolling Press Machine with Digital Micrometer

I'm Online Chat Now

Pouch Cell Battery Electrode Rolling Press Machine with Digital Micrometer

Pouch Cell Battery Electrode Rolling Press Machine with Digital Micrometer
Pouch Cell Battery Electrode Rolling Press Machine with Digital Micrometer

Large Image :  Pouch Cell Battery Electrode Rolling Press Machine with Digital Micrometer

Product Details:
Place of Origin: Shenzhen, China
Brand Name: TICO
Model Number: STC-DCM100
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Wood Packing
Delivery Time: 10-15 days
Payment Terms: T/T
Supply Ability: 50 sets per month

Pouch Cell Battery Electrode Rolling Press Machine with Digital Micrometer

Description
Product Name: Electric Rolling Press Calender Feature: With Digital Micrometer
Roller Size: φ100xW100mm. 150mm /200mm /250mm Width Roller Is Optional Pressing Thickness: 0~2mm Adjustable
Pressing Speed: 0~10mm/s Adjustable Function: For Rolling Press Battery Electrode After Coating And Drying

Pouch Cell Electrode Rolling Press Equipment



Brief Introduction



STC-DCM100 is used for battery electrode rolling press for battery research after coating and drying. It is with digital dial indicator, easy to operate. The pressing speed is digital display.



Features



●  Pressing thickness is adjustable and digital display.

●  Rolling pressing speed is digital display.

●  Vertical rollers installation design for convenient feeding and pressing for strip material.

●  Forward & backward are available.

●  Electric pressing makes uniform pressing force.



Technical Parameter



 Model  STC-DCM100
 Working voltage  AC110V/220V optional
 Roller size  φ100xW100mm. 150mm /200mm /250mm width roller optional
 Roller hardness  >HRC62
 Pressing thickness  0~2mm adjustable
 Digital Micrometer  resolution 0.01 and 0.001mm optional
 Pressing speed  0~10mm/s adjustable, digital display
 Power  120W
 Dimension  L390 * W250 * H356mm
 Weight  60kg



Warranty



1 year warranty with lifetime support. Man-made damage is not covered.



FAQ



1. Are you a manufacturer?



A: Yes, our factory is located in Shenzhen, China.
We have more than 10 year experience for manufacturing battery lab research equipment. We own a professional R&D department.



2. Do you accept customized product?

A: Yes. Most of our products can be customized to meet different requirements.



3. Will you provide test video before dispatch?

A: Yes, we take test video for every equipment before dispatch, which will display how to use it.



4. Can you offer overseas installation service?

A: Yes, we can dispatch professional engineer for on-site installation service.
