4x500ml Planetary Ball Milling Machine Gear Drive For Lab Research

I'm Online Chat Now

4x500ml Planetary Ball Milling Machine Gear Drive For Lab Research

4x500ml Planetary Ball Milling Machine Gear Drive For Lab Research
4x500ml Planetary Ball Milling Machine Gear Drive For Lab Research

Large Image :  4x500ml Planetary Ball Milling Machine Gear Drive For Lab Research

Product Details:
Place of Origin: Shenzhen, China
Brand Name: TICO
Model Number: STC-XQM-2A
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Wood Packing
Delivery Time: 15~ 20 working days
Payment Terms: T/T
Supply Ability: 30 sets per month

4x500ml Planetary Ball Milling Machine Gear Drive For Lab Research

Description
Product Name: Planetary Ball Mill Container Volume: 500ml/container, Total 2L
Container Qty: 4 Transmission Mode: Gear Drive
Working Mode: 2 Or 4 Containers Can Be Used Each Time Max Loading: 2/3 Of Milling Container
Dimension: L750 * W470 * H590mm Weight: 80kg
High Light:

4x500ml Planetary Ball Mill

,

Lab Planetary Ball Mill

,

Gear Drive Ball Milling Machine

4x500ml Planetary Ball Mill Gear Drive Ball Milling Machine for Lab Research



Brief Introduction



STC-XQM-2A planetary ball milling machine is widely used in many fields of geology, mine, metallurgy, electric industry, construction, ceramics, chemicals, light industry, medicine, etc. Different material of milling jar is optional according to the milled material. It is small size, low noise and high efficiency for laboratory.



Features



● Stable revolving speed of the gear transmission ensures the consistency and repeatability of the experiment.

● Planetary movement principle is adopted, which has high speed, large energy, high efficiency, small granularity.

● 4 milling containers included, 4 different material can be milled at same time.

● Rotating speed is adjustable by frequency converter.

● It has function of timing power off, self-timing forward and reversal rotating. One-way direction, alternation, continuous, time mode can be set.

● Different material of milling jar & balls optional.

● Compact size, low noise.



Technical Parameters



 Model  STC-XQM-2A
 Working voltage  AC110V/220V optional
 Volume of container  500ml/container, total 2L
 Container qty  4pcs
 Transmission mode  Gear drive
 Working mode  2 or 4 containers can be used each time
 Max loading  2/3 of milling container
 Feeding material

 Soft and crispy material≤10mm,

 other  material≤3mm

 Output granularity  Min reach to 0.1μm
 Power  0.75KW
 Total running time setting  1~9999 min
 Alternating Run Time of Forward & Reversal   Rotation  1~999 min
 Max continuous working time  72 hrs
 Speed

 Revolution: 35~355rpm

 Rotation:  70~670rpm

 Noise  60±5db
 Dimension  L750 * W470 * H590mm
 Weight  80kg



Warranty



1 year warranty with lifetime support. Man-made damage is not covered.



FAQ



1. Are you a manufacturer?



A: Yes, our factory is located in Shenzhen, China.
We have more than 10 year experience for manufacturing battery lab research equipment. We own a professional R&D department.



2. Do you accept customized product?

A: Yes. Most of our products can be customized to meet different requirements.



3. Will you provide test video before dispatch?

A: Yes, we take test video for every equipment before dispatch, which will display how to use it.



4. Can you offer overseas installation service?

A: Yes, we can dispatch professional engineer for on-site installation service.
