Battery Mixing Machine
Created with Pixso. 2*150ml Planetary Vacuum Centrifugal Mixing and Degassing Machine

2*150ml Planetary Vacuum Centrifugal Mixing and Degassing Machine

Brand Name: TICO
Model Number: STC-ETP-300
MOQ: 1 Set
Price: Negotiable
Delivery Time: 15~ 20 working days
Payment Terms: T/T
Detail Information
Place of Origin:
Shenzhen, China
Name:
Planetary Vacuum Centrifugal Mixing And Degassing Machine
Model:
STC-ETP-300
Dimension:
W300 * H490 * D370mm
Weight:
30kg
Packaging Details:
Wood Packing
Supply Ability:
20 sets per month
Highlight:

Semi Auto Pouch Cell Lab Equipment

,

Manual Pouch Cell Lab Equipment

,

220V Electrode Die Cutter

Product Description

2*150ml Planetary Vacuum Centrifugal Mixing and Degassing Machine

Brief Introduction

Adopting planetary vacuum mixing and degassing, it is suitable for mixing all kinds of liquid or powder materials, such as battery powder or slurry, carbon nanotubes, nano-powder, conductive ceramics, oxide powder and metal powder. Ensure that the samples are mixed in a vacuum state to achieve better experimental effects.

Key Features

● Adopting intelligent window design can clearly observe the mixing part of the machine.
● Stronger wind power, rapid heat dissipation, high rotation speed and mute.
● No contact, no mixing blade and minimize pollution.
● High precision with low friction coefficient, durable.
● Equipped with double mixing containers to achieve more capacity.
●The centrifugal force of rotation and the revolution cause convection to homogenize the sample material.
● Using vacuum pressure can effectively degassing sub-micron bubbles in the material.
● Touch screen human-machine control system, easy to operate, safe and practical.

Technical Parameters


ModelSTC-ETP-300
VoltageAC220V±10%, 50Hz
Power0.5KW
Standard container

150ml *2pcs (φ60 * H75mm),
10ml, 30ml, 50ml, 100ml container is available

Max processing capacity150g * 2
RevolutionStepless speed regulation (1~2000rpm), accuracy 1rpm
Rotation0.5 times of the revolution speed
Max rotation speed2000rpm
Time setting0 ~ 600s, 3 segments (accuracy 1s, 200s/segment)
Parameter storage6 groups
ViscosityMax 300,000cps
Working principlePlanetary gravity mixing/degassing
VacuumBuilt-in a vacuum pump
Vacuum pressure

-98Kpa, accuracy 0.1Kpa,
vacuum delay, vacuum degree arbitrary adjustment

Drive mode400W servo motor
Balance adjustmentDouble sides counterweight balance adjustment
Control systemDouble closed-loop PLC control, Chinese interface, touch screen operation
Lubrication systemCup sleeve anti-splash structure, passive lubrication, prevent bearing wear
Alarm functionYes, it will alarm when the upper cover not closed /overload
Safety functionYes, automatic stop when abnormal phenomenon occurs, upper cover automatic lock when running
Transmission modeGear drive
DimensionW300 * H490 * D370mm
Weight30kg


Warranty

1 year warranty with lifetime support. Man-made damage is not covered.

FAQ

1. Are you a manufacturer?

A: Yes, our factory is located in Shenzhen, China.
We have more than 10 year experience for manufacturing battery lab research equipment. We own a professional R&D department.


2. Do you accept customized product?
A: Yes. Most of our products can be customized to meet different requirements.


3. Will you provide test video before dispatch?
A: Yes, we take test video for every equipment before dispatch, which will display how to use it.


4. Can you offer overseas installation service?
A: Yes, we can dispatch professional engineer for on-site installation service.
