Customized Pouch Cell Lab Equipment Forming Machine 6mm Thickness Adjustable

Name: Customized Pouch Cell Lab Equipment Forming Machine 6mm Thickness Adjustable
Brand: Shenzhen TICO Technology Co.,Ltd.
SKU: STC-BCK-G65
Price: 4,000.00 USD
Availability: InStock

Brand Name:	TICO
Model Number:	STC-BCK-G65
MOQ:	1 Set
Price:	Negotiable
Delivery Time:	20~25 working days
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen, China

Product Name:

Gas Driven Pouch Cell Case Forming Machine

Driven Mode:

Gas Driven

Max Punching Size:

L65 * W50mm , Customized Size Is Available

Punching Thickness:

≤6mm Adjustable

Aluminum-laminated Film Thickness:

0.1~0.2mm

Aluminum-laminated Film Size:

L160 * W105 Mm

Capacity:

200~400pcs/h

Forming Pressure:

Max 1T

Dimension:

L360 * W230 * H340mm

Weight:

70kg

Packaging Details:

Wood Packing

Supply Ability:

20 sets per month

Highlight:

customized Pouch Cell Lab Equipment

6mm Thickness Pouch Cell Lab Equipment

Adjustable Pouch Cell Forming Machine

Product Description

Gas Driven Pouch Cell Case Forming Machine for Pouch Cell Preparation

Brife Introduction

STC-BCK-G65 is a gas driven machine for aluminum-laminated film pouch cell case forming. The case punching depth can be adjustable. The compact design makes it the perfect tool for research or sample making.

Features

● Gas driven, electric is not required.

● Punching speed is adjustable.

● Punching pressure is adjustable.

● Different punching die can be optional and replaced, easy to replace optional die.

● The punching die can go down only by pressing 2 start buttons at the same to avoid hands injured.

● Punched case without crow's feet and corner collapse.

● Compact size can be used on desk or into glove box.

Technical Parameters

Model	STC-BCK-G65
Driven mode	Gas driven
Max punching size	L65 * W50mm, customized size is available
Punching thickness	≤6mm adjustable
Case forming accuracy	±0.05mm
Aluminum-laminated film thickness	0.1~0.2mm
Aluminum-laminated film size	L160 * W105mm
Capacity	200~400pcs/h
Forming pressure	Max 1T
Dimension	L360 * W230 * H340mm
Weight	70kg

Warranty

1 year warranty with lifetime support. Man-made damage is not covered.

FAQ

1. Are you a manufacturer?

A: Yes, our factory is located in Shenzhen, China.
We have more than 10 year experience for manufacturing battery lab research equipment. We own a professional R&D department.

2. Do you accept customized product?

A: Yes. Most of our products can be customized to meet different requirements.

3. Will you provide test video before dispatch?

A: Yes, we take test video for every equipment before dispatch, which will display how to use it.

4. Can you offer overseas installation service?

A: Yes, we can dispatch professional engineer for on-site installation service.
