products details

Home Products

4*1L Lab Planetary Ball Milling Machine

Brand Name:	TICO
Model Number:	STC-XQM-4A
MOQ:	1 Set
Price:	Negotiable
Delivery Time:	15~ 20 working days
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen, China

Product Name:

Planetary Ball Mill

Container Volume:

1L, 1L/container

Container Qty:

Transmission Mode:

Gear Drive

Working Mode:

2 Or 4 Containers Can Be Used Each Time

Max Loading:

2/3 Of Milling Container

Dimension:

L750 * W470 * H564mm

Weight:

80kg

Packaging Details:

Wood Packing

Supply Ability:

30 sets per month

Highlight:

Gear Drive Ball Milling Machine

Lithium Ion Battery Ball Milling Machine

0.75KW Planetary Milling Machine

Product Description

4 * 1L Lab Planetary Ball Milling Machine

Brief Introduction

It is widely used in many fields of geology, mine, metallurgy, electric industry, construction, ceramics, chemicals, light industry, medicine, etc. Different material of milling jar is optional according to the milled material. It is small size, low noise and high efficiency for laboratory.

Key Features

● Stable revolving speed of the gear transmission ensures the consistency and repeatability of the experiment.
● Planetary movement principle is adopted, which has high speed, large energy, high efficiency, small granularity.
● 4 milling containers included, 4 different material can be milled at same time.
● Rotating speed is adjustable by frequency converter.
● It has function of timing power off, self-timing forward and reversal rotating. One-way direction, alternation, continuous, time mode can be set.
● Different material of milling jar & balls optional.
● Compact size, low noise.

Technical Parameters

Model	STC-XQM-4A
Working voltage	AC220V±10%, 50Hz
Volume of container	1000ml/ container, total 4L
Container qty	4 pcs
Transmission mode	Gear drive
Working mode	2 or 4 containers can be used each time
Max loading	2/3 of milling container
Feeding material	Soft and crispy material≤10mm, other material≤3mm
Output granularity	Min reach to 0.1μm
Power	0.75KW
Total running time setting	1~9999 min
Alternating running time of forward & reversal rotation	1~999 min
Max continuous working time	72 hrs
Speed	Revolution: 35~335 rpm Rotating: 70~670 rpm
Noise	60±5db
Dimension	L750 * W470 * H564mm
Weight	80kg

Warranty

1 year warranty with lifetime support. Man-made damage is not covered.

FAQ

1. Are you a manufacturer?

A: Yes, our factory is located in Shenzhen, China.
We have more than 10 year experience for manufacturing battery lab research equipment. We own a professional R&D department.

2. Do you accept customized product?
A: Yes. Most of our products can be customized to meet different requirements.

3. Will you provide test video before dispatch?
A: Yes, we take test video for every equipment before dispatch, which will display how to use it.

4. Can you offer overseas installation service?
A: Yes, we can dispatch professional engineer for on-site installation service.
