4 X 100ml Planetary Ball Mill For Cylindrical Battery Lab Research 0.25KW

4 X 100ml Planetary Ball Mill For Cylindrical Battery Lab Research 0.25KW
4 X 100ml Planetary Ball Mill For Cylindrical Battery Lab Research 0.25KW

Large Image :  4 X 100ml Planetary Ball Mill For Cylindrical Battery Lab Research 0.25KW

Product Details:
Place of Origin: Shenzhen, China
Brand Name: TICO
Model Number: STC-XQM0.4R
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: USD2200~USD5000
Packaging Details: Wood Packing
Delivery Time: 7~10 working day
Payment Terms: T/T
Supply Ability: 20 sets/month

4 X 100ml Planetary Ball Mill For Cylindrical Battery Lab Research 0.25KW

Description
Product Name: Planetary Ball Mill Container Qty: 4
Working Voltage: AC110V/220V Optional Power: 0.25KW
Total Running Time: 1~9999 Min Speed: Revolution: 45~435rpm / Rotation: 90~870rpm
High Light:

4 X 100ml Planetary Ball Mill

,

Cylindrical Battery Planetary Ball Mill

,

220V Lab Ball Mill

4 x 100ml Planetary Ball Mill



Brief Introduction



STC-XQMR0.4 planetary ball mill is widely used in many fields of geology, mine, metallurgy, electric industry, construction, ceramics, chemicals, light industry, medicine, etc. Different material of milling jar is optional according to the milled material. It is small size, low noise and high efficiency for laboratory.



Features



• Stable revolving speed of the gear transmission ensures the consistency and repeatability of the experiment.

• Adopts planetary movement principle, which has high speed, large energy, high efficiency, small granularity.

• 4 milling containers included, 4 different material can be milled at same time.

• Rotating speed is adjustable by frequency converter.

• With functions of timing power off, self-timing forward and reversal rotating. One-way direction, alternation, continuous, time mode can be set.

• Different material of milling jar & balls optional.

• Compact size, low noise.



Technical Details



 Brand name  TICO
 Working voltage  AC220V
 Volume of container  100ml/container, total 0.4L
 Container qty  4
 Transmission mode  Gear drive
 Working mode  2 or 4 containers can be used each time
 Max loading  2/3 of milling container
 Feeding material  Soft and crispy material≤10mm, other material≤3mm
 Output granularity  Min reach to 0.1µm
 Power  0.25KW
 Total running time setting  1~9999 min
 Alternating Run Time of Forward & Reversal Rotation  1~999 min
 Max continuous working time  72 hrs
 Speed

 Revolution: 45~435rpm,

 Rotation: 90~870rpm

 Noise  58±5db
 Dimension  L500 * W300 * H340mm
 Weight  30kg





Warranty



1 year warranty with lifetime support. Man-made damage is not covered.



FAQ



1. Are you a manufacturer?



A: Yes, our factory is located in Shenzhen, China.
We have more than 10 year experience for manufacturing battery lab research equipment. We own a professional R&D department.



2. Do you accept customized product?

A: Yes. Most of our products can be customized to meet different requirements.



3. Will you provide test video before dispatch?

A: Yes, we take test video for every equipment before dispatch, which will display how to use it.



4. Can you offer overseas installation service?

A: Yes, we can dispatch professional engineer for on-site installation service.
