Battery Electrode Vacuum Drying Machine Four Doors Circular 30KW

Battery Electrode Vacuum Drying Machine Four Doors Circular 30KW
Battery Electrode Vacuum Drying Machine Four Doors Circular 30KW

Large Image :  Battery Electrode Vacuum Drying Machine Four Doors Circular 30KW

Product Details:
Place of Origin: Shenzhen, China
Brand Name: TICO
Model Number: STC-YKX4
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Standard export wooden packing
Delivery Time: 15~20 working days
Payment Terms: T/T
Supply Ability: 50 sets per month

Battery Electrode Vacuum Drying Machine Four Doors Circular 30KW

Product Name: 4 Oven Type Vauum Drying Machine Oven Shape: Circular
Inner Liner Dimension: Ø450mm×D600mm Temperature: RT~150 ℃ Adjustable
Working Voltage: AC380V Total Power: 30KW
High Light:

Circular Vacuum Drying Machine


Electrode Vacuum Drying Machine


30KW Battery Drying Machine

Four Doors Circular Vacuum Drying Machine For Battery Electrode


Brief Introduction


STC-YKX4 vacuum oven is equipped with stainless steel liner, independent relay control and accurate temperature control. Heating vacuum pumping and nitrogen filling are controlled by buttons. In the middle, there is one Ø3"×D630mm cantilever shaft which can withstand 250kg material.




• It adopts pneumatic valve, vacuuming and nitrogen filling, which has high efficiency, saves personnel and has good product perdormance.

• 4 cylinders design, 5mm thick stainless steel inner tank, strong corrosion resistance, each one  is controlled separated without affecting each other.

• It adopts 304 stainless steelheating tube coiled liner heating type, and the temperature is controlled evenly.

• It is sealing with silicone rubber sealing strip, the door is made of 15mm thick tempered glass.

• The four  circular oven is controlled separately, total drying time, cycle time and vacuum pressure can be set separately according to customer.

• Elastic double-layer glass door with overpressure protection.

• PID adjustment, small termal inertia, good temperature control effect.

• The screen system adopts the centralized operation of the touch screen, which is convenient to operate and reliable to control.


Technical Parameters


 Brand name  TICO
 Model  STC-YKX4
 Temperature  RT~150 ℃  adjustable
 Inner liner dimension  Ø450mm×D600mm
 Working voltage  AC380V
 Total power  30KW
 Inner chamber temperature error  ±3 ℃ (No load in vacuum state)
 Heating time  The temperature rise from toom temperature to 100 ℃ in no-load state is less than 40 minutes. The cell core temperature stablization time is 110 mihnutes
 Main heating temperature control accuracy  Displayed temperature accuracy within<1 ℃
 Main heating temperature rise control  The safetty switch is set at 150 ℃ during heating
 Drying method  The heating tube surrounds the inner tank for heating
 Vacuum degree  -0.1Mpa
 Vacuum maintaining time  ≥98% for 24 hours at -0.1Mpa
 Control method  PLC, relay control
 Circulating air system  Including circulating air system, which cancarry out process programming and realize automatic control.
 Protect functions

 Automatic overtemperature alarm;

 Power failure automatic proteection function

 Dimension  L2050× W1240× H2010mm
 Weight  ≈1000kg




1 year's warranty with lifetime technical support.




1. Are you a manufacture ?

A: Yes,our factory is located in Shenzhen, China. We have more than 10 years experience for manufacturing battery lab research equipment.

We owns a professional R&D department.


2. Do you accept customized product ?

A:  Yes. Most of our products can be customized to meet different requirments.


3. Will you provide test video before dispatch ?

A: Yes, we take test video for every equipment before dispatchm which will display how to use it.


4. Can you offer overseas installation service ?

A: Yes, we can dispatch professional engineer for on-site installion service.
