Adjustable Automatic Film Casting Doctor Blade Max. 100mm Width

I'm Online Chat Now

Adjustable Automatic Film Casting Doctor Blade Max. 100mm Width

Adjustable Automatic Film Casting Doctor Blade Max. 100mm Width
Adjustable Automatic Film Casting Doctor Blade Max. 100mm Width

Large Image :  Adjustable Automatic Film Casting Doctor Blade Max. 100mm Width

Product Details:
Place of Origin: Shenzhen, China
Brand Name: TICO
Model Number: STC-TMG100
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Carton Box
Delivery Time: 4~7 days
Payment Terms: T/T
Supply Ability: 500 sets per month

Adjustable Automatic Film Casting Doctor Blade Max. 100mm Width

Description
Product Name: Film Coating Applicator Coating Thickness: 0~3500μm
Micrometer Accuracy: 1 μm Material: Corrosion Resistant Material
Coating Width: 100mm Maximum Feature: Coating Width Adjustable Within 100mm
High Light:

Adjustable Film Casting Doctor Blade

,

100mm Film Casting Doctor Blade

,

automatic film coater doctor blade

100mm Width Micrometer Adjustable Film Doctor Blade



Brief Introduction



It is a compact device for various of coating research for lab, especially for battery electrode coating, ceramic coating, nano film, etc. The coating width can be adjusted.



Features



● Coating thickness is adjustable between 0~3500μm.

● 100mm width, the other width is optional.

● Double micrometer to control the coating thickness, high coating accuracy.

● Stainless steel corrosion resistance material, longer lifetime.

● Black color, easy to clean.



Technical Parameters



 Brand name  TICO
 Model  STC-TMG100
 Coating width  100mm
 Coating Thickness adjust range  0~3500μm
 Micrometer Accuracy  10μm
 Material  Corrosion resistant material
 Dimension  L120 x W87 x H110mm



FAQ



1. Are you a manufacturer ?



A: Yes, our factory is located in Shenzhen, China.

We have more than 10 years experience for manufacturing battery lab research equipment. We owns a professional R&D department.



2. Do you accept customized product ?

A : Yes. Most of our products can be customzied to meet different requirements.



3. Will you provide test video before dispatch ?

A : Yes, we take test video for every equipment before dispatch, which will display how to use it.



4. Can you offer overseas installation service ?

A : Yes, we can dispatch professional engineer for on-site installation service.
