Product Details:
|
| Product Name: | Film Coating Applicator | Coating Width: | 150mm Max. |
|---|---|---|---|
| Coating Thickness: | 0~3500μm | Adjust Scale: | 10μm |
| Material: | Corrosion Resistance Material | Feature: | Coating Width Adjustable |
| High Light: | 150mm Adjustable Film Applicator,10μm Adjustable Film Applicator,Electrode Lithium Ion Battery Assembly Line |
||
150mm Adjustable Doctor Blade Film Coater for Battery Electrode Coating
Brief Introduction
STC-TMT150 is a compact device for various of coating research for lab, especially for battery electrode coating, ceramic coating, nano film, etc. The coating width can be adjusted.
Features
● Coating thickness is adjustable between 0~3500μm.
● 100mm width, the other width is optional.
● Double micrometer to control the coating thickness, high coating accuracy.
● Stainless steel corrosion resistance material, longer lifetime.
● Black color, easy for clean.
Technical Parameters
| Brand name | TICO |
| Model | STC-TMT150 |
| Coating width | 150mm adjustable |
| Coating thickness adjust range | 0~3500μm |
| Adjust accuracy | 10μm |
| Material | Corrosion resistance material |
| Dimension | L120 x W87 x H110mm |
Warranty
1 year's warranty with lifetime support.
FAQ
1. Are you a manufacturer ?
A: Yes, our factory is located in Shenzhen, China.
We have more than 10 years experience for manufacturing battery lab research equipment. We owns a professional R& D department.
2. Do you accept customized product ?
A : Yes. Most of our products can be customzied to meet different requirements.
3. Will you provide test video before dispatch ?
A : Yes, we take test video for every equipment before dispatch, which will display how to use it.
4. Can you offer overseas installation service ?
A : Yes, we can dispatch professional engineer for on-site installation service.
