Product Details:
|
| Model: | STC-ZYB01 | Application: | For Battery Electrolyte Injection |
|---|---|---|---|
| Pump Core Material: | ZrO2, Al2O3 | Drive Method: | Imported Servo Motor/Stepper Motor |
| Range Of Rotation: | 1-1200rpm Forward And Reverse Reversible | Protection Level: | IP31 |
Lab Electrolyte Filling Pump Device for Battery Liquid Injecting
Brief Introduction
It is applied for precision measurement of high-end micro liquid medium in medicine, electrolyte, acid, solvent, diary products, glue, reagent and other industries. The high precision and compact design make it particularly perfect for battery electrolyte filling in battery lab research.
Features
• Suitable for high-end micro-precision liquid medium metering filling, adding, liquid injection/injecting, spraying and marking. Valveless design ensures stable flow.
• The pump core is made of special industrial ceramics (Zirconium Oxide ZrO2, Alumina Al2 O3), which has features of high-strength wear resistance, with anti-chemical reaction, the contact medium part is ceramic.
• The pump sleeve and parts are resistant to acid and alkali, suitable for metering in various harsh liquid environment.
• Positive displacement plunger structure, reciprocating rotation operation, adjust the stroke length and rotation period to change the flow rate.
• The system is with powerful functions, multi-capacity, multi-speed options, and can transform and transfer liquid in reverse.
Technical Parameter
| Brand name | TICO |
| Model | STC-ZYB01 |
| Pump core material | ZrO2, Al2O3 |
| Pump core performance | Corrosion resistance, high temperature resistance, wear resistance, high hardness, low friction coefficient, long life |
| Pump core matching accuracy | 2 μm |
| Drive method | Imported Servo Motor/Stepper Motor |
| Range of rotation | 1-1200rpm forward and reverse reversible |
| Speed control method | pulse |
| Control display method | Display control 4.3 inches touch screen man-machine interface dialogue operation |
| Programming software | Display and Control Programmable Controller |
| Single stroke capacity range | 0 μL -10000 μL, Max10000 /1 stroke |
| Capacity calculation method | Q total (total liquid volume) = Q stroke (stroke volume) × N stroke (stroke number) |
| Measurement accuracy | Within 5‰ |
| Applicable medium temperature | The temperature of the medium liquid is less than or equal to 250 ℃ (due to the different material selection, please specify when placing the order) |
| Catheter | PE / Teflon / inlet inside diameter φ6, the outer diameter φ8 |
| Dispensing needle | Φ2.5/Φ4.0/Φ6.0 (Needle and needle length optional) |
| Metering pump size | L×W×H 201×125×147mm |
| Controller size | L×W×H 295×215×157mm |
| Weight | ≈8kg including controller and metering pump |
| Applicable power supply | AC 220V±10%, 50Hz/60Hz (standard) AC 110V±10%, 50Hz/60Hz (optional) |
| Working environment | Temperature 0～40℃, relative humidity <80% |
| Protection level | IP31 |
Warranty
1 year warranty with lifetime support. Man-made damage is not covered.
FAQ
1. Are you a manufacturer?
A: Yes, our factory is located in Shenzhen, China.
We have more than 10 Year experience for manufacturing battery lab research equipment. We own a professional R&D department.
2. Do you accept customized product?
A: Yes. Most of our products can be customized to meet different requirements.
3. Will you provide test video before dispatch?
A: Yes, we take test video for every equipment before dispatch, which will display how to use it.
4. Can you offer overseas installation service?
A: Yes, we can dispatch professional engineer for on-site installation service.
