Product Details:
|
| Product Name: | One Work Station Glovebox | Glove Material: | Butyl |
|---|---|---|---|
| High Light: | Battery Fabrication Vacuum Glovebox,Two Sided Vacuum Glovebox,Butyl Lab Vacuum Glove box |
||
Two Sided 2 Work Station Vacuum Glovebox with Inter of Things for Lab Battery Fabrication
Brief Introduction
STC-VGB-12 is a 2 work stations glove box, one work station is in the front, and the other one is in the back. It is an internet of things vacuum glove box, integrated device management intelligent analysis & pre-warning of equipment status, the abnormal alarm message is actively sended, troubleshooting remotely and debugging online. It is widely applied in Lithium Battery, Physical Chemistry, OLED&PLED, Organometallic, Solar Cell, Semi-Conductor, Catalyst, Material Handling, Fine Chemicals, Polymeric Materials, Powder Metallurgy, Special Welding, Special Lamps, Nuclear Technology, Pharmaceutical etc.
Features
● Intelligent analysis & early warning of equipment status, the abnormal alarm message is actively pushed, remote fault diagnosis and online debugging
● H2O & O2<1ppm
● This machine own the low leak rate
● PLC control, and Color Touchscreen HMI, Automatic purge; Circulation; Regeneration; Pressure control; User Friendly Interface.
● It is widly applied in lab battery research and develpment
● Various of components used in this machine is world famous brand
● 1 case with 2 work stations, one work station is in front, and the other one is in the back
Main Data
1) H2O & O2: <1ppm
2) Leakage rate of box: 0.05 vol％/h
Technical Parameter
| Glovebox House | |
| House | Material: Stainless steel type 304, thickness 3mm |
| Inner surface: Brushed finish | |
| External surface: Enameled, White | |
| Inside dimension: L1220 * W100 * H900mm | |
| Window | Safety glass with thin film, thickness 8mm |
| Glove port | POM, O ring sealed, 2 ports |
| Gloves |
1 pair, Butyl, thickness 0.4mm, Dia. 8 inch x length 32 inch |
| Dust filter | 0.3 micron,1 gas inlet and 1 gas outlet filter included |
| Shelves | 2 layers shelves inside, height adjustable |
| Light | LED light front mounted |
| Feedthrough |
DN 40 KF: several pieces Electrical feedthrough: 1 electrical plug for inside |
| Vacuum Chamber | |
| Big Antechamber | |
| Chamber |
Inside dimension: φ360mm x L600mm |
| Material: Stainless steel type 304 | |
| Surface: Brushed finish inside and Painted white outside | |
| Accessories |
Door: double door, anodized aluminium Material: Stainless steel type 304 Thickness: 10mm |
| Manometer: Analog display | |
| Control | Manual |
| Mini Antechamber | |
| Chamber | Inside dimension: φ150mm x L300mm |
| Material: Stainless steel type 304 | |
| Surface: Brushed finish inside and Painted white outside | |
| Accessories |
Door: double door, anodized aluminium Material: Stainless steel type 304 Thickness: 10mm |
| Manometer: Analog display | |
| Control | Manual |
| Gas Purification | |
| Purifier | Function: Removal of H2O and O2 |
| Container material: Stainless steel type 304 | |
|
Absorber unit: Copper catalyst: 5 Kg Molecular sieve: 5 Kg |
|
|
Capacity of purifying: Removal of 60L O2, Removal of 2Kg H2O |
|
| H2O and O2: less than 1ppm | |
| Gas Circulation | Working gas: Nitrogen, Argon and Helium |
| Blower: 90m3/h | |
| Regeneration | Operation: Auto. PLC controlled Regeneration. |
| Regeneration gas: working gas / H2 mixture (H2: 5-10%) | |
| Pump | Type: 12m3 /h Rotary vane pump, Oil mist Angle valves, Gas ballast control. |
| Valves | Main valves: DN 40 KF electro-pneum. Angle valves |
| Controlling System | |
| Function | Includes self-diagnosis, electric failure and restart, pressure controlling and self-adapt, circulation controlling, code protection, union controlling adopts, SIEMENS PLC touch screen etc. |
| Pressure controlling | The pressure in the box is controlled by PLC, the pressure can be settled between +/- 10mbar, while beyond +/- 12mbar the system will automatically protect itself. |
| Foot switch | Controlling the pressure, easy to raise or depress the pressure |
| Accessories | |
| Moisture Analyzer | Measuring Range: 0~500ppm, display by PLC |
| Oxygen Analyzer | 0~1000ppm, display by PLC |
| Internet of things system | |
| Function |
|
Warranty
1 year warranty with lifetime support. Man-made damage is not included.
FAQ
1. Are you a manufacturer?
A: Yes, our factory is located in Shenzhen, China.
We have more than 10 year experience for manufacturing battery lab research equipment. We own a professional R&D department.
2. Do you accept customized product?
A: Yes. Most of our products can be customized to meet different requirements.
3. Will you provide test video before dispatch?
A: Yes, we prepare test video for every equipment before dispatch, which will show you how to use it.
4. Can you offer overseas installation service?
A: Yes, we can dispatch professional engineer for on-site installation service.
