Product Details:
|
| Drying Chamber Qty: | 2 Sets | Coating Method: | 3 Rollers Transfer Coating |
|---|---|---|---|
| Coating Mode: | Continuous & Intermittent Coating | Roller Width: | 330mm |
| Effective Coating Width: | 280mm | Substrate Thickness: | Aluminium Foil: 8~30μm Copper Foil: 8~30μm |
| High Light: | Roll Transfer Battery Coating Machine,330mm Battery Coating Machine,Lithium Ion Pouch Cell Assembly |
||
Product Introduction
STC-RTCA300-2JF is a film transfer coating equipment with three rollers, which is mainly used in continuous and intermittent coating film for battery electrode produce or production line. It can be widely applied in the surface coating of various substrates, especially in lithium-ion battery industry. This machine is designed in accordance with the convenience of researchers, and meets the requirements of coating precision and consistency. It owns the excellent drying function, and also is an ideal choice for lithium-ion battery, super capacitor, nickel battery and other battery research and development and small trial production.
Key Features
● Each part of drying cabinet temperature can be controlled independently.
● This machine is the modular design, which is easier to operate.
● Continuous and intermittent coating can be changed freely.
● Tension control, it’s equipped with correction device.
● Lower & upper blowing heating oven with excellent drying.
● Comma coating blade metering, with precision adjustment mechanism to obtain high coating accuracy.
● Gap tracking system for double side coating.
● PLC control, high automation.
Technical Parameter
| Brand name | TICO |
| Coating method | 3 rollers transfer coating |
| Coating mode | Continuous & intermittent coating |
| Roller width | 330mm |
| Effective coating width | 280mm |
| Substrate thickness |
Aluminium foil: 8~30μm Copper foil: 8~30μm |
| Coating speed | 0~0.5m/min, depending on the heating |
| Single side coating thickness after drying | 20-200μm |
| Heating temperature | RT~150℃ |
| Heating oven | 1m length, customized length is available |
| Coating size accuracy | L≤±1mm, W≤±0.5mm |
| Voltage | 3PH 380V, 50Hz |
| Total power | 10KW |
| Compressed air | 0.5~0.7Mpa |
| Dimension | L5000*W1300*H1500mm |
Warranty
1 year warranty with lifetime support. Man-made damage is not included.
FAQ
1. Are you a manufacturer?
A: Yes, our factory is located in Shenzhen, China.
We have more than 10 Year experience for manufacturing battery lab research equipment. We own a professional R&D department.
2. Do you accept customized product?
A: Yes. Most of our products can be customized to meet different requirements.
3. Will you provide test video before dispatch?
A: Yes, we take test video for every equipment before dispatch, which will display how to use it.
4. Can you offer overseas installation service?
A: Yes, we can dispatch professional engineer for on-site installation service.
