Product Details:
Place of Origin: Shen Zhen, China
Brand Name: TICO
Model Number: STC-RTCA300-3JF
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Standard export wooden packing
Delivery Time: 15~20 working days
Payment Terms: T/T
Supply Ability: 30 sets per month

Transfer Film Battery Coating Machine Continuous Roll To Roll 3PH 380V 50Hz

Description
Drying Chamber Qty: 3 Sets Coating Method: 3 Rollers Transfer Coating
Roller Width: 330mm (280mm Effective) Heating Temperature: RT~150℃
Heating Oven: 1m Length ,customizable Dimension: L6500*W1300*H1500mm
High Light:

3PH Battery Coating Machine

,

Roll To Roll Battery Coating Machine

,

Transfer Film Coating Machine

Product Introduction



STC-RTCA300-3JF is a film transfer coating equipment with three rollers, which is mainly used in continuous and intermittent coating film for battery electrode produce or production line. It can be widely applied in the surface coating of various substrates, especially in lithium-ion battery industry. This machine is designed in accordance with the convenience of researchers, and meets the requirements of coating precision and consistency. It owns the excellent drying function, and also is an ideal choice for lithium-ion battery, super capacitor, nickel battery and other battery research and development and small trial production.



Key Features



● Each part of drying cabinet temperature can be controlled independently.

● This machine is the modular design, which is easier to operate.

● Continuous and intermittent coating can be changed freely.

● Tension control, it’s equipped with correction device.

● Lower & upper blowing heating oven with excellent drying.

● Comma coating blade metering, with precision adjustment mechanism to obtain high coating accuracy.

● Gap tracking system for double side coating.

● PLC control, high automation.



Technical Parameter



 Brand name  TICO
 Coating method  3 rollers transfer coating
 Coating mode  Continuous & intermittent coating
 Roller width  330mm
 Effective coating width  280mm
 Substrate thickness

 Aluminium foil: 8~30μm

 Copper foil: 8~30μm

 Coating speed  0~0.5m/min, depending on the heating
 Single side coating thickness after drying   20-200μm
 Heating temperature  RT~150℃
 Heating oven  1m length ,customized length is available
 Coating size accuracy   L≤±1mm, W≤±0.5mm
 Voltage  3PH 380V 50Hz
 Total power  10KW
 Compressed air  0.5~0.7Mpa
 Dimension  L6500*W1300*H1500mm



Warranty



1 year warranty with lifetime support. Man-made damage is not included.



FAQ



1. Are you a manufacturer?



A: Yes, our factory is located in Shenzhen, China.
We have more than 10 Year experience for manufacturing battery lab research equipment. We own a professional R&D department.



2. Do you accept customized product?

A: Yes. Most of our products can be customized to meet different requirements.



3. Will you provide test video before dispatch?

A: Yes, we take test video for every equipment before dispatch, which will display how to use it.



4. Can you offer overseas installation service?

A: Yes, we can dispatch professional engineer for on-site installation service.
