Micro Vibration Ball Milling Machine For Lab Research 240V 50Hz

I'm Online Chat Now

Micro Vibration Ball Milling Machine For Lab Research 240V 50Hz

Micro Vibration Ball Milling Machine For Lab Research 240V 50Hz
Micro Vibration Ball Milling Machine For Lab Research 240V 50Hz

Large Image :  Micro Vibration Ball Milling Machine For Lab Research 240V 50Hz

Product Details:
Place of Origin: Shen Zhen, China
Brand Name: TICO
Model Number: STC-WQM1
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Standard export wooden packing
Delivery Time: 5~8 working days
Payment Terms: T/T
Supply Ability: 50 sets per month

Micro Vibration Ball Milling Machine For Lab Research 240V 50Hz

Description
Working Voltage: Single Phase Power AC 208V~240V / 50Hz Rotating Speed: 2700~4000 Rpm
Timer: 3~180s Screw Microtube: 2ml
Zirconia Microspheres: Φ0.1mm, Φ0.5mm, Φ1.0mm, Φ1.5mm, Φ 3.0mm Weight: 2.2 Kg
High Light:

Vibration Ball Milling Machine

,

Lab Ball Milling Machine

,

240V Micro Ball Mill

Micro Vibration Ball Milling Machine for Lab Research



Product details



STC-WQM1 Micro vibration ball milling machine is a high-power micro vibration ball milling and material mixing machine, which is suitable for small batch material ball milling and mixing of small amounts of substances. It used 2 ml disposable screw microtubes, and mixing of 3 samples can be performed simultaneously (usually can be performed within 45s). The mixing pattern can be optimized by selecting a high-speed impact of zirconia microspheres specifically matched to the sample. This machine device is developed and designed to overcome the highstrength samples that are difficult to mix evenly by traditional mixers, which is owning the features of convenient and economical.



Key feature



• Other dimension zirconia microspheres can be available.

• High purity zirconia microspheres, it can adapt to high impact strength and high-speed milling.

• 3 samples can be performed per time, high efficiency.

• Milling time can be set according to requirement.

• Pretty design, it is the ideal machine for high strength sample.



Technical parameter



 Brand name  TICO
 Working voltage  single phase power AC 208V~240V / 50Hz
 Rotating speed  2700~4000 rpm
 Timer  3~180s
 Screw microtube  2ml
 zirconia microspheres    Φ0.1mm, Φ0.5mm, Φ1.0mm, Φ1.5mm, Φ 3.0mm,other size can be available.
 Dimension  L170*W210*H135mm
 Weight  2.2 kg



Warranty



1 year warranty with lifetime support. Man-made damage is not covered.



FAQ



1. Are you a manufacturer?



A: Yes, our factory is located in Shenzhen, China.
We have more than 10 year experience for manufacturing battery lab research equipment. We own a professional R&D department.



2. Do you accept customized product?

A: Yes. Most of our products can be customized to meet different requirements.



3. Will you provide test video before dispatch?

A: Yes, we take test video for every equipment before dispatch, which will display how to use it.



4. Can you offer overseas installation service?

A: Yes, we can dispatch professional engineer for on-site installation service.
