PLC Control Supercapacitor Production Line Grooving Pre-Sealing Machine 2.5Kw

PLC Control Supercapacitor Production Line Grooving Pre-Sealing Machine 2.5Kw
PLC Control Supercapacitor Production Line Grooving Pre-Sealing Machine 2.5Kw

Large Image :  PLC Control Supercapacitor Production Line Grooving Pre-Sealing Machine 2.5Kw

Product Details:
Place of Origin: Shen Zhen, China
Brand Name: TICO
Model Number: STC-GCK60
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Standard export wooden packing
Delivery Time: 15~20 working days
Payment Terms: T/T
Supply Ability: 50 sets per month

PLC Control Supercapacitor Production Line Grooving Pre-Sealing Machine 2.5Kw

Description
Function: Supcapacitor Case Grooving, Pre-sealing And Crimping Power: 2.5Kw
Application: Φ60 Battery And Supercapacitor Cells, With A Length Of H50~150mm Can Be Customized Grooving Width: 1.4mm (optional)
Grooving Die Lifetime: ≥5000 000 Times Capacity: ≥ 3 PCS
High Light:

PLC Control Supercapacitor Production Line

,

2.5Kw Supercapacitor Production Line

,

SuperCapacitor Grooving Line

Super Capacitor Grooving & Pre-sealing Machine for Production Line



Production details



It is suitable for grooving, pre-sealing and crimping of supercapacitor cases.



Features



• Grooving and sealing are driven precisely by the servo motor. The feed distance and speed are controlled accurately to be kept stable, without rebound (the cylinder will rebound under compression resistance).

• The grooving and sealing dimensions of supercapacitors can be set on the HMI, and adjusted automatically and precisely to the required data.

• The pressing speed for sealing changes from quick feeding to slow crimping.

• The product is clamped securely by the jacket, with high centering coaxiality, but no shaking. It is grooved and sealed evenly with good out-off-roundness.

• Feeding is guided by the high-precision linear guide rail set, to ensure high accuracy and stable dimensions of grooving and sealing.

• The PLC control and HMI are conductive to automation.

• The outer cover is used for intelligent protective and safe and reliable use, and the external geometry is exquisite, neat and conducive to operation.



Technical parameter



 Model  STC-GCFK60
 Power supply  AC220V, 50Hz
 Power  2.5Kw
 Application  Φ60 battery and supercapacitor cells, with a length of H50~150mm can be customized
 Capacitor height HA after sealing  ±0.05mm
 Grooving height accuracy LB  ±0.05mm
 Grooving depth accuracy LA  ±0.02mm
 Grooving width  1.4mm (optional)
 Grooving die lifetime  ≥5000 000 times
 Capacity  ≥ 3 PCS
 Utilization rate  98%
 Air source  0.5MPa~0.7MPa, adjustable
 Air comsumption  0.2m3 /min
 Dimension  L1100 * W640 * H1700mm
 Weight  550kg



Warranty



1 year warranty with lifetime support. Man-made damage is not covered.



FAQ



1. Are you a manufacturer?

A: Yes, our factory is located in Shenzhen, China.

We have more than 10 Year experience for manufacturing battery lab research equipment. We own a professional R&D department.



2. Do you accept customized product?

A: Yes, most of our products can be customized to meet different requirements.



3. Will you provide test video before dispatch?

A: Yes, we take test video for every equipment before dispatch, which will display how to use it.



4. Can you offer overseas installation service?

A: Yes, we can dispatch professional engineer for on-site installation service.
