Automatic Supercapacitor Vacuum Electrode Drying Oven 8Kw

Automatic Supercapacitor Vacuum Electrode Drying Oven 8Kw
Automatic Supercapacitor Vacuum Electrode Drying Oven 8Kw

Large Image :  Automatic Supercapacitor Vacuum Electrode Drying Oven 8Kw

Product Details:
Place of Origin: Shen Zhen
Brand Name: TICO
Model Number: STC-KX6N
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Standard export wooden packing
Delivery Time: 15~20 working days
Payment Terms: T/T
Supply Ability: 50 sets per month

Automatic Supercapacitor Vacuum Electrode Drying Oven 8Kw

Description
Toatl Power: 8Kw Vacuum Chamber Size: L580 * W420 * H380mm
Gas Source: 0.5~0.7MPa Outline Dimensions: L1600 * W1300 * H2000mm
Capacity: 168 Capacitors (calculated Based On Φ60. L138)
High Light:

Automatic Electrode Drying Oven

,

8Kw Electrode Drying Oven

,

Supercapacitor Vacuum Drying Oven

Supercapacitor Vacuum Drying Oven



Production introduction



It is mainly used for vacuum drying, nitrogen filling and cyclic baking of batteries and supercapacitors. The product is kept in an anhydrous and oxygen-free environment and transferred into the glove box for liquid injection.



Key features



● It is the square chamber designing, the heating distance is equal and balanced.

● Six vacuum chambers work, each chamber of temperature and pressure is digital displayed separately.

● Automatic control system and touch screen display, it is flexible and simple to operate

● High quality imported materials and components, which are durable and stable.

● The oven is externally coating with varnish, the appearance is neat, elegant and not easy to fall off.

● Gases supplied by high-quality corrugated hoses connect with stainless steel pipes.

● Gas pipes can be changed quickly.



Technical parameters



 Model  STC-KX6N
 Working voltage  3-Ph, AC380V, 50hz
 Total power  8Kw
 Temperature range  Ambient temp~+180℃
 Temperature resolution  0.1℃
 Temperature fluctuation  ≤±2℃
 Temperature uniformity  ≤±2℃
 Heating time  ≤30min from the ambient temperature to 140℃
 Temperature overshoot  <5℃, with the over-temperature alarm device
 Vacuum (depending on the vacuum capacity of the vacuum pump)  Vacuum chamber  ≤0.007 mbar under no load
 Leakage rate  ≤1×10-6 mbar*1/s
 Capacity  168 capacitors (calculated based on Φ60. L138)
 Gas source  0.5~0.7MPa
 Weight  600kg
 Vacuum chamber size  L580 * W420 * H380mm
 Outline dimensions  L1600 * W1300 * H2000mm



Warranty



1 year warranty with lifetime support. Man-made damage is not covered.



FAQ



1. Are you a manufacturer?

A: Yes, our factory is located in Shenzhen, China.

We have more than 10 Year experience for manufacturing battery lab research equipment. We own a professional R&D department.



2. Do you accept customized product?

A: Yes, most of our products can be customized to meet different requirements.



3. Will you provide test video before dispatch?

A: Yes, we take test video for every equipment before dispatch, which will display how to use it.



4. Can you offer overseas installation service?

A: Yes, we can dispatch professional engineer for on-site installation service.
