Product Details:
|
| Application: | Φ60 Batteries And Supercapacitor | Injection Accuracy: | ±1% |
|---|---|---|---|
| Vacuum Degree: | Above -98KPa | Whole Machine Material: | Corrosion Resistance |
| Dimension Of Double Station: | L900 * W800 * H900mm | Control Box Size: | L1100 * W400 * H720mm |
| High Light: | 98KPa Electrode Injecting Machine,1KW Electrode Injecting Machine,Corrosion Resistance Supercapacitor Injecting Machine |
||
Supercapacitor Electrode Injecting Machine
Product Introduction
It is suitable for supercapacitor injection by means of vacuuming, injection and pressurization, which features high consistency, reliability and safety of electrolyte absorption.
Key features
● Valve assembly and piping layout for injection structure are constantly optimized to completely resolve electrolyte corrosion and crystallization.
● This machine is designed with multi-stage filter and special material adsorption system to prevent the failure in starting the pump impeller for vacuuming.
● Electrolyte is rarely exposed in the injection, low volatilization and damage to others components of the glovebox.
● Easy-to-dismantle filter and access hole are used for cleaning easily, save cost and time.
● The DCM cleaning function is mainly for monthly and quarterly cleaning, to keep the pipeline clean.
● High measurement accuracy and repetition consistency, the electrolyte accuracy within ±0.1%.
Technical parameter
| Model | STC-ZY60 |
| Voltage | AC220V, 50Hz |
| Power | 1 KW |
| Application | Φ60 batteries supercapacitor, with a length of H50~150mm can be customized |
| Injection accuracy | ±1% |
| Injection volume | 0~250ml, adjustable |
| Vacuum degree | Above -98KPa |
| Vacuuming time | Low vacuum, injection time, standing time, pressure and pressurization time are adjustable |
| Connectors of injection tank material | Stainless steel |
| PE hoses material | Corrosion resistant |
| Whole machine material | Corrosion resistant |
| Machine body material | 6 series aluminum alloy |
| Capacity | It takes 12 min per injection cycle, and 6 batteries can be injected in 6 stations |
| Operation | The six stations can be operated separately without interference |
| Nitrogen (consistent with the working gas of the glove box) | ≥0.4MPa |
| Dimension of double station | L900 * W800 * H900mm |
| Control box size | L1100 * W400 * H720mm |
Warranty
1 year warranty with lifetime support. Man-made damage is not covered.
FAQ
1. Are you a manufacturer?
A: Yes, our factory is located in Shenzhen, China.
We have more than 10 Year experience for manufacturing battery lab research equipment. We own a professional R&D department.
2. Do you accept customized product?
A: Yes, most of our products can be customized to meet different requirements.
3. Will you provide test video before dispatch?
A: Yes, we take test video for every equipment before dispatch, which will display how to use it.
4. Can you offer overseas installation service?
A: Yes, we can dispatch professional engineer for on-site installation service.
