Product Details:
|
| Model: | STC-JG-5L | Slurry Feeding: | Speed Adjustable Peristaltic Pump |
|---|---|---|---|
| Slurry Viscosity: | 2000~12000 MPas | Feeding Speed: | <450 Ml/min |
| Buffer Tank Material: | SUS 304 Stainless Steel | Effective Volumme: | 5L |
| High Light: | Electrode Battery Mixing Machine,Adjustable Battery Mixing Machine,240V Battery Slurry Feeding System |
||
Slurry Feeding System for Battery Electrode Film Coating Machine
Product Introduction
STC-JG-5L slurry feeding system is mainly used for slurry feeding when battery electrode coating, and also can be applied in other slurry feeding. It has exquisite appearance, and equips with speed adjustable peristaltic pump that is capable to carry out feeding slurry high-accuracy.
Key features
● The machine appearance is made of corrosion resistance material.
● Anti-corrosion pipes can be applied for acid-base slurry. Other type of tubes can be customized.
● The flow of slurry rate is adjustable to match the film coating machine needed.
● Small size, convenient for maintenance.
● It is capable to carry out the linakge control feeding with our film coating machine.
● The buffer tank has the mixing function on or off.
Technical paramter
| Model | STC-JG-5L |
| Voltage | AC100~240V±10%, 50~60Hz |
| Power | 100W |
| Slurry feeding | Speed adjustable peristaltic pump |
| Slurry viscosity | 2000~12000 mPas |
| Feeding speed | <450 ml/min |
| Rotating speed | <150 rpm |
| Mixing method | Anchor mixing, mixing speed is adjustable |
| Buffer tank material | SUS 304 stainless steel |
| Effective volume | 5L |
| Dimension | L600 * W320 * H780mm |
| Weight | 50kg |
Warranty
1 year warranty with lifetime support. Man-made damage is not covered.
FAQ
1. Are you a manufacturer?
A: Yes, our factory is located in Shenzhen, China.
We have more than 10 Year experience for manufacturing battery lab research equipment. We own a professional R&D department.
2. Do you accept customized product?
A: Yes, most of our products can be customized to meet different requirements.
3. Will you provide test video before dispatch?
A: Yes, we take test video for every equipment before dispatch, which will display how to use it.
4. Can you offer overseas installation service?
A: Yes, we can dispatch professional engineer for on-site installation service
