Product Details:
|
| Model: | STC-G07103 | Power: | 4Kw |
|---|---|---|---|
| Chamber Material: | Alumina Ceramic Fiber | Chamber Size: | L300 * W200 * H120mm |
| Heating Element: | OCr27A17Mo2 | Volume: | 7L |
| High Light: | R D Laboratory Dry Oven,Box Type Laboratory Dry Oven,7L Muffle Furance |
||
Laboartory Muffle Furance Box-type Drying Chamber for R&D
Product Introductions
This furnace is mainly used for carrying out the sintering, annealing and oxidation experiment for ceramic material, composite material, mental material, functional material, heating material, crystal material, etc. It is widely used for universities, research institutes, enterprise R&D centers, quality inspection units, processing industries, etc.
Key Features
• Automatic power off when open the door.
• It will power off and alarm automatically when the temperature exceeds the pre-set temp.
• It will automatically cut off power to avoid electricity leakage.
• The temperature control system adopts artificial intelligence adjustment technology, which is owning the PID automatic control, fuzzy control, auto-tune function, and programmable for temp control.
• The furnace inside is equipped with 485 Conversion Interface, which is capable to carry out connecting with one or up to 200 furnaces by professional computer control system to realize the remote control, real-time track, data record, output report and etc.
• The furnace inside is made of Alumina ceramics by vacuum adsorption. Energy saving, heating evenly.
Technical Parameter
| Model | STC-G07103 |
| Voltage | AC220V |
| Power | 4Kw |
| Chamber material | Alumina ceramic fiber |
| Chamber size | L300 * W200 * H120mm |
| Temperature accuracy | ±1.0℃ |
| Opering method | Side door design, power off whrn open the door |
| Max temperature | 1000℃ |
| Heating element | OCr27Al17Mo2 |
| Furnace structure | Integrartion of heating box and controlling box |
| Temperature control | PID automatic control and 30 segments programmable for temperature control |
| Temperature | Type "K" thermocouple |
| Volume | 7L |
| Size | L590 * W460 * H638mm |
| Weight | 70kg |
| Remark | sintering corrosive & volatile samples are prohibited |
Warranty
1 year warranty with lifetime support. Man-made damage is not covered.
FAQ
1. Are you a manufacturer?
A: Yes, our factory is located in Shenzhen, China.
We have more than 10 Year experience for manufacturing battery lab research equipment. We own a professional R&D department.
2. Do you accept customized product?
A: Yes, most of our products can be customized to meet different requirements.
3. Will you provide test video before dispatch?
A: Yes, we take test video for every equipment before dispatch, which will display how to use it.
4. Can you offer overseas installation service?
A: Yes, we can dispatch professional engineer for on-site installation service.
