Product Details:
|
| Container Volume: | 2L, 500ml/container | Container Qty: | 4 |
|---|---|---|---|
| Transmission Mode: | Gear Drive | Working Mode: | 2 Or 4 Containers Can Be Used Each Time |
| Max Loading: | 2/3 Of Milling Container | Dimension: | L750 * W470 * H590mm |
| Weight: | 80kg | ||
| High Light: | 4 X 500ml Ball Milling Machine,Planetary Ball Milling Machine,Lab Planetary Milling Machine |
||
4 x 500ml Lab Planetary Ball Milling Machine for Cylindrical Battery Making
Brief Introduction
STC-XQM-2A planetary ball mill is widely used in many fields of geology, mine, metallurgy, electric industry, construction, ceramics, chemicals, light industry, medicine, etc. Different material of milling jar is optional according to the milled material. It is small size, low noise and high efficiency for laboratory.
Features
● Stable revolving speed of the gear transmission ensures the consistency and repeatability of the experiment.
● Planetary movement principle is adopted, which has high speed, large energy, high efficiency, small granularity.
● 4 milling containers included, 4 different material can be milled at same time.
● Rotating speed is adjustable by frequency converter.
● It has function of timing power off, self-timing forward and reversal rotating. One-way direction, alternation, continuous, time mode can be set.
● Different material of milling jar & balls optional.
● Compact size, low noise.
Technical Parameters
| Model | STC-XQM-2A |
| Working voltage | AC110V/220V optional |
| Volume of container | 500ml/container, total 2L |
| Container qty | 4pcs |
| Transmission mode | Gear drive |
| Working mode | 2 or 4 containers can be used each time |
| Max loading | 2/3 of milling container |
| Feeding material |
Soft and crispy material≤10mm, other material≤3mm |
| Output granularity | Min reach to 0.1μm |
| Power | 0.75KW |
| Total running time setting | 1~9999 min |
| Alternating Run Time of Forward & Reversal Rotation | 1~999 min |
| Max continuous working time | 72 hrs |
| Speed |
Revolution: 35~355rpm |
| Noise | 60±5db |
| Dimension | L750 * W470 * H590mm |
| Weight | 80kg |
Warranty
1 year warranty with lifetime support. Man-made damage is not covered.
FAQ
1. Are you a manufacturer?
A: Yes, our factory is located in Shenzhen, China.
We have more than 10 year experience for manufacturing battery lab research equipment. We own a professional R&D department.
2. Do you accept customized product?
A: Yes. Most of our products can be customized to meet different requirements.
3. Will you provide test video before dispatch?
A: Yes, we take test video for every equipment before dispatch, which will display how to use it.
4. Can you offer overseas installation service?
A: Yes, we can dispatch professional engineer for on-site installation service.
