Planetary Ball Grinding Equipment for Lab Lithium Coin Cell Battery Research

Planetary Ball Grinding Equipment for Lab Lithium Coin Cell Battery Research
Planetary Ball Grinding Equipment for Lab Lithium Coin Cell Battery Research

Large Image :  Planetary Ball Grinding Equipment for Lab Lithium Coin Cell Battery Research

Product Details:
Place of Origin: Shen Zhen
Brand Name: TICO
Model Number: STC-XQM0.2R
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: USD2200~USD5000
Packaging Details: Standard export wooden packing
Delivery Time: 7~10 working day
Payment Terms: T/T
Supply Ability: 20 sets/month

Planetary Ball Grinding Equipment for Lab Lithium Coin Cell Battery Research

Description
Container Qty: 4 Pieces Transmission Mode: Gear Drive
Power: 0.25KW Total Running Time: 1~9999 Min
Speed: Revolution: 35~355rpm / Rotation: 70~670rpm

Product Details



STC-XQM0.2R planetary ball grinding equipment is widely used in many fields like geology, mine, metallurgy, electric industry, construction, ceramics, chemicals, light industry, medicine, etc. Different material of milling jar is optional according to the milled material. It is small size, low noise and high efficiency for laboratory.



Features



• Stable revolving speed of the gear transmission ensures the consistency and repeatability of the experiment.

• Planetary movement principle is adopted, with features of high speed, large energy, high efficiency, small granularity.

• 4 milling containers design allows 4 different material can be milled at the same time.

• Rotating speed is adjustable by frequency converter.

• With functions of timing power off, self-timing forward and reversal rotating. One-way direction, alternation, continuous, time mode can be set.

• Different material of milling jar & balls optional.

• Compact size, low noise.

• Visible window to observe the operation.



Technical Details



 Model  STC-XQM0.2R
 Working voltage  AC110V/220V optional
 Volume of container  50ml/container ,total 0.2L
 Container qty  4pcs
 Transmission mode  Gear drive
 Working mode  2 or 4 containers can be used each time
 Max loading  2/3 of milling container
 Feeding material

 Soft and crispy material≤10mm,

 other material≤3mm

 Output granularity  Min reach to 0.1µm
 Power  0.25KW
 Total running time setting  1~9999 min
 Alternating Run Time of Forward & Reversal Rotation  1~999 min
 Max continuous working time  72 hrs
 Speed

 Revolution: 35~355rpm / Rotation: 70~670rpm

 Noise  58±5db
 Dimension  L250* W425 * H280mm
 Weight  30kg



Warranty



1 year warranty with lifetime support.



FAQ



1. Are you a manufacturer?



A: Yes, our factory is located in Shenzhen, China.
We have more than 10 year experience for manufacturing battery lab research equipment. We own a professional R&D department.



2. Do you accept customized product?

A: Yes. Most of our products can be customized to meet different requirements.



3. Will you provide test video before dispatch?

A: Yes, we take test video for every equipment before dispatch, which will display how to use it.



4. Can you offer overseas installation service?

A: Yes, we can dispatch professional engineer for on-site installation service.
