32700 Cylindrical Cell Case

Brand Name:	TICO
Model Number:	STC-CGK-32700
MOQ:	1 set
Price:	Negotiable
Delivery Time:	5~8 working days
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen

Name:

32700 Cylindrical Cell

Material:

Nickel Plated Steel

Packaging Details:

Cartoon Packing (Optional according to quantity)

Supply Ability:

200000 sets per month

Highlight:

21700 Cylindrical Battery Materials

18650 Cylindrical Battery Materials

SUS 304 Cylindrical Cell Case

Product Description

32700 Cylindrical Cell Case

Technical Parameters

Model	STC-CGK-32700
Material	Nickel plated steel
Height	72.80＋0.05/－0.09mm
Diameter of the case flaring	Mouth outer: 32.34＋0.07/－0.09mm Inner: 31.50±0.05mm Outer: 32.34＋0.04/－0.09mm
Diameter of middle part	Outer: 32.20＋0.06/－0.04mm Inner: 31.50±0.05mm
Diameter of bottom	26.50±0.50
Thickness of case wall	Mouth: 0.42±0.02mm Middle bottom: 0.34±0.02mm
Thickness of nickel coating	6.0mm away from the outer wall of the case: 2.5~7μm 36.0±5.0mm away from the outer wall mouth of the case: ≥ 2.5μm 16.0mm away from the outer wall edge of the bottom of the case: ≥ 0.25μm 36±5mm away from the inner wall mouth of the case: ≥ 2.5μm
R angle	15±0.08mm
