Product Details:
|
| Model: | STC-TMH250L | Heating Type: | Top Heating |
|---|---|---|---|
| Vacuum Pump: | Built-in Type | Max Heating Temperature: | 150℃ |
| Coating Length: | 250mm Maximum | Doctor Blade: | 100mm Fixed Width As Standard, Other Size Optional |
| High Light: | Top Heating Battery Tape Casting Machine,Electrode Battery Tape Casting Machine,Automatic Battery Casting Machine |
||
Automatic Battery Tape Casting Machine with Hoting Cover for Battery Electrode Making
Brief Introduction
STC-TMH250L is a compact film tape casting machine with hoting cover, which is widely used in all kinds film coating research, like ceramic films, crystal films, lithium battery electrode coating, etc.
Features
• Touch screen operation, high automation.
• Vacuum aluminium chuck is designed for quick suction of substrate.
• Built-in type vacuum pump.
• Coating stroke length can be set.
• Heating temperature up to 150℃ adjustable, and it's digital display.
Technical Parameters
| Working voltage | AC110V |
| Coating length | Max 250mm adjustable |
| Doctor blade | 100mm fixed width as standard, other size is optional |
| Coating thickness | 0.01~3.5mm adjustable |
| Vacuum chuck | L365 x W200 x H30mm |
| Vacuum pump | Internal |
| Coating speed | 0~200mm/s adjustable |
| Heating temperature | RT~150℃ adjustable, digital display |
| Heating temperature accuracy | ±1℃ |
| Dimension | L490 x W300 x H340mm |
| Weight | 42kg |
Warranty
1 year's warranty with lifetime support.
FAQ
1. Are you a manufacturer ?
A: Yes, our factory is located in Shenzhen, China.
We have more than 10 years experience for manufacturing battery lab research equipment. We own a professional R& D department.
2. Do you accept customized product ?
A : Yes. Most of our products can be customzied to meet different requirements.
3. Will you provide test video before dispatch?
A : Yes, we take test video for every equipment before dispatch, which will display how to use it.
4. Can you offer overseas installation service ?
A : Yes, we can dispatch professional engineer for on-site installation service.
