Product Details:
|
| Model: | STC-YZF10 | Sorting Channel Qty: | 9 OK Channels + 1 NG Channel |
|---|---|---|---|
| Voltage: | AC220V+10%, 50Hz | Power: | ≤1000w |
| Dimension: | L1370 * W780 * H1450mm | Weight: | 260kg |
| High Light: | Cylindrical Battery Sorting Machine,10 Channels Battery Sorting Machine,18650 Battery Production Line |
||
10 Channels Cylindrical Battery Sorting Machine for Battery Production Line 18650, 21700, 26650, 32700 Cylindrical Cell
Product Details
Cylindrical cell sorting machine is applied in battery grade sorting by testing battery internal resistance and voltage, which is equipped with high precision internal resistance & voltage testing system. It can be used for sorting various models of cylindrical cell 18650, 21700, 26650, 32700, etc. The batteries will be sent to the specified channels according to preset value, 9 OK channels +1 NG channel.
Key Features
• Automatically testing battery for internal resistance &voltage.
• Multi-channels design, 9 OK channels + 1 NG channels.
• Equipped with high-precision testing system for battery internal resistance and voltage sorting according to the pre-set values.
• High working efficiency, sorting faster.
• Universal wheel makes it easy for moving.
Technical Parameters
| Model | STC-YZF10 |
| Voltage | AC220V+10%, 50Hz |
| Power | ≤1000w |
| Application | Cylindrical cell 18650, 21700, 26650, 32700, etc. |
| Sorting channel qty | 9 OK channels + 1 NG channel |
| Filure rate of NG | ≤ 1% |
| Accuracy |
Voltage: 0.01mV, 0.001mV is optional Internal resistance:0.01mΩ, 0.001 mΩ is optional |
| Compressed air | 0.5~0.7MPa |
| Working temperature | 0~40℃ |
| Humidity | ≤85% |
| Working surroundings | Working surroundings |
| Damage rate of product | ≤0.05% |
| Working efficiency | ≥4800/h |
| Dimension | L1370 * W780 * H1450mm |
| Weight | 260kg |
Warranty
1 year warranty with lifetime support. Man-made damage is not covered.
FAQ
1. Are you a manufacturer?
A: Yes, our factory is located in Shenzhen, China.
We have more than 10 Year experience for manufacturing battery lab research equipment. We own a professional R&D department.
2. Do you accept customized product?
A: Yes, most of our products can be customized to meet different requirements.
3. Will you provide test video before dispatch?
A: Yes, we take test video for every equipment before dispatch, which will display how to use it.
4. Can you offer overseas installation service?
A: Yes, we can dispatch professional engineer for on-site installation service.
