15T Coin Cell Lab Equipment Single Punch Hydraulic Tablet Press Machine

15T 	Coin Cell Lab Equipment Single Punch Hydraulic Tablet Press Machine
15T 	Coin Cell Lab Equipment Single Punch Hydraulic Tablet Press Machine

Large Image :  15T Coin Cell Lab Equipment Single Punch Hydraulic Tablet Press Machine

Product Details:
Place of Origin: Shen Zhen, China
Brand Name: TICO
Model Number: STC-SYP15
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Standard export wooden packing
Delivery Time: 15~20 working days
Payment Terms: T/T
Supply Ability: 100 sets per month

15T Coin Cell Lab Equipment Single Punch Hydraulic Tablet Press Machine

Description
Product Name: Hydraulic Coin Cell Tablet Making Machine Product Type: STC-SYP15
Pressure Range: 0~150T Piston Type: Chrome-plated Oil Cylinder
Piston Diameter: Φ80mm Piston Stroke: 30mm Maximum
High Light:

15T Coin Cell Lab Equipment

,

Single Punch Coin Cell Lab Equipment

,

30mm Hydraulic Tablet Press Machine

Brief Introduction



Tablet pressing machine is used for pressing the powder into piece, which is widely applied in scientific research, teaching, testing, pharmacy, catalysis, chemical industry, etc.



Features



• Chrome-plated oil cylinder features smooth surface, and anti-corrosion.

• Excellent rubber gasket sealing and leakage-proof.

• Optimized structure, oil pool, mainboard and oil cylinder are integrated on the same mainboard.

• Aluminum alloy hand-wheel, anti-corrosion and durable.

• Small size, light weight, leakage-proof, it can be used in glovebox.

• High qualify steel is used for pressing die to ensure longer lifetime.



Technical Details



 Model  STC-SYP15
 Pressure range  0~15T
 Piston diameter  Chrome-plated oil cylinder Φ80mm
 Max piston stroke  30mm
 Pressure stability  ≤1MPa/10min
 Dimension  L245 * W175 * H390mm
 Weight  40kg



Warranty



1 year warranty with lifetime support. Man-made damage is not covered.



FAQ



1. Are you a manufacturer?



A: Yes, our factory is located in Shenzhen, China.

We have more than 10 Year experience for manufacturing battery lab research equipment. We own a professional R&D department.



2. Do you accept customized product?

A: Yes, most of our products can be customized to meet different requirements.



3. Will you provide test video before dispatch?

A: Yes, we take test video for every equipment before dispatch, which will display how to use it.



4. Can you offer overseas installation service?

A: Yes, we can dispatch professional engineer for on-site installation service.
