| Brand Name: | TICO |
| Model Number: | STC-FQM-6L |
| MOQ: | 1 Set |
| Price: | USD2200~USD5000 |
| Delivery Time: | 7~10 working day |
| Payment Terms: | T/T |
Square Shape Laboratory Ball Milling Machine for Battery Research
Brief Introduction
STC-FQM-6L planetary ball mill is widely used in many fields of geology, mine, metallurgy, electric industry, construction, ceramics, chemicals, light industry, medicine, etc. Different material of milling jar is optional according to the milled material. It is small size, low noise and high efficiency for laboratory.
Features
• Stable revolving speed of the gear transmission ensures the consistency and repeatability of the experiment.
• Adopts planetary movement principle, which has high speed, large energy, high efficiency, small granularity.
• 4 milling containers included, 4 different material can be milled at same time.
• Rotating speed is adjustable by frequency converter.
• With functions of timing power off, self-timing forward and reversal rotating. One-way direction, alternation, continuous, time mode can be set.
• Different material of milling jar & balls optional.
• Compact size, low noise.
Technical Details
| Brand name | TICO |
| Working voltage | AC220V |
| Volume of container | 1.5L/container, total 6 L |
| Container qty | 4 |
| Transmission mode | Gear drive |
| Working mode | 2 or 4 containers can be used each time |
| Max loading | 2/3 of milling container |
| Feeding material | Soft and crispy material≤10mm, other material≤3mm |
| Noise | 58±5db |
| Dimension | L770 * W470 * H570mm |
| Weight | 120kg |
Warranty
1 year warranty with lifetime support. Man-made damage is not covered.
FAQ
1. Are you a manufacturer?
A: Yes, our factory is located in Shenzhen, China.
We have more than 10 year experience for manufacturing battery lab research equipment. We own a professional R&D department.
2. Do you accept customized product?
A: Yes. Most of our products can be customized to meet different requirements.
3. Will you provide test video before dispatch?
A: Yes, we take test video for every equipment before dispatch, which will display how to use it.
4. Can you offer overseas installation service?
A: Yes, we can dispatch professional engineer for on-site installation service.
|
|
