Automatic Cylindrical Cell Battery Crimping Machine For Lab Lithium Ion Pilot Line

Name: Automatic Cylindrical Cell Battery Crimping Machine For Lab Lithium Ion Pilot Line
Brand: Shenzhen TICO Technology Co.,Ltd.
SKU: STC-CLF-18
Price: 1,500.00 USD
Availability: InStock

Brand Name:	TICO
Model Number:	STC-CLF-18
MOQ:	1 set
Price:	Negotiable
Delivery Time:	5~8 working days
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen, China

Application:

Cylindrical Cell Manufacturing

Key Character:

PLC Touch Screen Operation

Crimping Die:

18650 Cylindrical Cell Crimping Die Is Standard, Other Die Is Optional

Crimping Pressure:

Max. 3000kg

Crimping Accuracy:

±0.1mm

Sturcture Material:

High Quality Steel

Packaging Details:

Standard export wooden package

Supply Ability:

200 set per month

Highlight:

PLC Battery Crimping Machine

Lithium Ion Battery Crimping Machine

Automatic Crimping Cylindrical Cell Lab Equipment

Product Description

Automatic Cylindrical Cell Crimping Machine

Product Details

It is an automatic crimping machine for cylindrical cell case with automatic feeding & discharging. After 3 sealing process, it carried out flat sealing edge, good air tightness, high dimensional accuracy, high efficiency, excellent consistency.

Key Features

• PLC touch screen operation for parameters setting easily, high automation.

• After 3 sealing processes, it carried out flat sealing edge, good air tightness, high dimensional accuracy, high efficiency, excellent consistency.

• High accuracy crimping die ensures excellent crimping and forming. It designed with high quality steel structure, stable &safety for operation.

• Various of crimping die is optional for cylindrical cell making.

• Exquisite appearance, small volume, convenient for operation.

Technical Parameters

Model	STC-CLF-18
Voltage	AC220V, 50Hz
Power	0.2Kw
Crimping die	Cylindrical cell 18650 crimping die is stanard, others die is optional
Crimping pressure	Max. 3000kg
Crimping accuracy	± 0.1mm
Die lifetime	≥3000 000 times
Capacity	6 pcs/min
Compressed air	0.5~0.7MPa
Dimension	L550 * W420 * H800mm
Weight	150kg

Warranty

1 year warranty with lifetime support. Man-made damage is not covered.

FAQ

1. Are you a manufacturer?

A: Yes, our factory is located in Shenzhen, China.
We have more than 10 year experience for manufacturing battery lab research equipment. We own a professional R&D department.

2. Do you accept customized product?

A: Yes. Most of our products can be customized to meet different requirements.

3. Will you provide test video before dispatch?

A: Yes, we take test video for every equipment before dispatch, which will display how to use it.

4. Can you offer overseas installation service?

A: Yes, we can dispatch professional engineer for on-site installation service.
