Product Details:
|
| Application: | Cylindrical Cell Electrolyte Filling | Key Characters: | 2 Working Steps. Electrolyte Filling And Diffusion |
|---|---|---|---|
| High Filling Accuracy: | Within ±0.5% | Inlet & Outlet: | Chemical Resistant Soft Hose |
| Key Components Material: | SUS 304/316 Stainless Steel | Volume Degree: | Above -98KPa |
| High Light: | SUS 316 Electrolyte Filling Machine,SUS 304 Electrolyte Filling Machine,Electrolyte Standing Cylindrical Cell Lab Equipment |
||
Vacuum Electrolyte Filling & Standing Machine
Product Details
It is suitable for supercapacity &battery electrolyte injection and standing. 2 working steps, firstly electrolyte filling, secondly electrolytre diffiusion. It features high consistency and reliability.
Key Features
• 2 filing chambers for electrolyte filling and standing process alternately.
• It integrates electrolyte filling and vacuum standing functions.
• It has excellent measurement accuracy and consistency for electrolyte filling.
• Filling after vacuuming, high efficiency &accuracy, convenient for operation.
• Filling accuracy within ±0.5%, filling volume 0.2~200ml adjustable.
• Chemical resistant soft hose is useful for inlet and outlet.
• Operation in glovebox and drying room are available.
• High automation, with PLC and touch screem opertion for parameters setting.
• Key components are made of SUS 304/316, with good corrosion resistance.
• Electrolyte injection speed, filling volume, vacuum degree, pressure holding time &standing time are adjustable.
Technical Parameters
| Model | STC-ZBF65 |
| Voltage | AC220V, 50Hz |
| Power | 1Kw |
| Working efficiency | 35 pcs for one chamber (21700 cylindrical cell for reference ) |
| Filling speed | 0.1~20ml/s adjustable |
| Injection accuracy | ±0.5% |
| Capacity volume | 0.2~200ml*N cycles |
| Battery core filling speed | 0.2~200g*N cycles |
| Electrolyte filling speed | 0.1~20ml/s adjustable |
| Compressed air | 0.5MPa |
| Vacuum degree | Above -98KPa |
| Dimension | L950 * W450 * H800mm |
| Weight | 120kg |
Warranty
1 year warranty with lifetime support. Man-made damage is not covered.
FAQ
1. Are you a manufacturer?
A: Yes, our factory is located in Shenzhen, China.
We have more than 10 year experience for manufacturing battery lab research equipment. We own a professional R&D department.
2. Do you accept customized product?
A: Yes. Most of our products can be customized to meet different requirements.
3. Will you provide test video before dispatch?
A: Yes, we take test video for every equipment before dispatch, which will display how to use it.
4. Can you offer overseas installation service?
A: Yes, we can dispatch professional engineer for on-site installation service.
