Battery Slurry Feeding System
Product Details
This slurry feeding system is used for battery electrode coating slurry feeding, and also cna be applied in others slurry feeding. It has exquisite appearance, equips with two pumps and cache tanks for cathode & anode slurry feeding for high efficiency operation,
Key Features
• The machine body is made of anti-resistance material.
• The pipeline is corrosion reisistance, which can be applied in various of acidic & alkaline battery slurry. Customized pipeline is available.
• Two sets of peristaltic pump and cache tank for anode & cathode slurry feeding separately.
• The floe of slurry rate is adjustable to meet the film coating machine's requirement.
• Exquisite size, easy for maintenance.
• It is capable to carry out the linkage control feeding with our film coating machine.
Technical Parameters
| Model | STC-ESL-1L |
| Voltage | AC110~240V±10%, 50Hz |
| Power | 0.1Kw |
| Slurry feeding pump | 2 peristaltic pumps for anode & cathode slurry feeding separately |
| Slurry flowing rtate | 19~65ml/min adjustable |
| Pipeline diameter | 5mm |
| Slurry viscosity | 2000~12000m Pas |
| Cache tank volume | 1L |
| Cache tank material | SUS 304 stainless steel |
| Machine's body material | Corrosion resistance material |
| Dimension | L320 * W181 * H200mm |
| Weight | 3kg |
Warranty
1 year warranty with lifetime support. Man-made damage is not covered.
FAQ
1. Are you a manufacturer?
A: Yes, our factory is located in Shenzhen, China.
We have more than 10 year experience for manufacturing battery lab research equipment. We own a professional R&D department.
2. Do you accept customized product?
A: Yes. Most of our products can be customized to meet different requirements.
3. Will you provide test video before dispatch?
A: Yes, we take test video for every equipment before dispatch, which will display how to use it.
4. Can you offer overseas installation service?
A: Yes, we can dispatch professional engineer for on-site installation service.
|
|
