80 Channels 5V 6A Battery Testing Machine With Three Range Output

80 Channels 5V 6A Battery Testing Machine With Three Range Output
80 Channels 5V 6A Battery Testing Machine With Three Range Output

Large Image :  80 Channels 5V 6A Battery Testing Machine With Three Range Output

Product Details:
Place of Origin: Shenzhen, China
Brand Name: TICO
Model Number: STC-40080-5V6A-S1
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Standard export wooden package
Delivery Time: 5~8 working days
Payment Terms: T/T
Supply Ability: 200

80 Channels 5V 6A Battery Testing Machine With Three Range Output

Application: Supercapacity Cell & Battery Capacity Testing Key Features: 80 Testing Channels, Three Range Output
Dimension: L483 * W404 * H1300mm High Accuracy: ±0.05%FS
Input Power: 425W
High Light:

425W Battery Testing Machine


5V 6A Battery Testing Machine


AC220V Battery Testing Equipment

80 Channels Battery Testing Machine


Product Details


STC-40080-5V6A-S1 is a three range output current tester, 0.5mA~1A, 0.1A~3A, 3A~6A. The accuracy for current and voltage on these channels is ±0.05% FS. It has 80 channels, each channels is working independently. The flexibility of this tester allows it to be used for a wide range of applications such as materials research, quality control in manufacturing, research & development, battery and cell testing, Supercapacitor testing, etc.


Key Features


• Multi ranges.

• Width application.

• High accuracy, ±0.05%FS.

• Fast response time.

• Each channels is independent.

• Side air intake on the left/ right side & eight test channels, the inventive heat-radiating system is practical and feasible and can increasing heat-radiating efficiency and space ulilization rate.


Technical Parameters


 Input power  AC220V±10%, 50Hz

 AD: 16bit;

 DA: 16bit

 Input resistance  ≥1GΩ
 Input power  425W
 Channels features  Constant current source and constant voltage source with independent pairs if closed-loop structure
 Channel control mode  Independent control
 Voltage  Per channel control voltage range  25mV~5V
 Minium discharge voltage  Upper and lower clamp discharge to 1V, 2m cables to 1.5V
 Accuracy  ±0.0.5% of FS
 Stability  ±0.0.5% of FS
 Current  Per-channel current range

 Range 1: 0.5mA~0.1A,

 Range 2: 0.1A~3A,

 Range 3: 3A~6A

 Constant current cut-off current

 Range 1: 0.2mA,

 Range 2: 6mA,

 Range 3: 12mA

 Accuracy  ±0.05% of FS
 Stability  ±0.05% of FS
 Power  Per channel output power  30w
 Stability  ±0.05% of FS
 Time  Current response time  <1ms
 Step time range  ≤(365*24)hours/step, Time form support 00: 00: 00.000(h, min , s, ms)
 Date recording  Record condition  Time△t: 100ms
 Voltage△U: 10mV


Range 1: 2mA,

Range 2: 6mA,

Range 3: 12mA

 Record frequency


 Charge  Charge mode  Constant current charge, constant voltage charge, constant current and constant voltage charge, constant power charge
 End condition  Voltage current, relative time capacity, -△V
 Discharge  Discharge mode  Constanr current dischage, constant voltage discharge constant current and constant voltage discharge, constant power discharge, constant resistance discharge
 End condition  Voltage current, relative time, capacity, -△V
 Pulse test  Charge  Constant current charge, constant power charge
 Discharge  Constant current discharge, constant power discharge
 Miniumum pulse width  500ms
 Pulse number  32 different pulse for a single step
  Charge and discharge switch  continuous switched for a single pulse step
 End condition  Voltage, relative time
 DCIR test supported
 Cycle  Loop measure range  1~65535 times
 Max steps per loop  254
 Nested loop  Nested loop function, max support  3 layers
 Protection  Power down data protection
 Off line testing function
 Setting protection condition, setting parameter: low voltage limit, upper voltgae limit, low current limit, upper current limit, anti-reverse protection model
 Voltage and current testing sample  4-wire connecting
 Noise  <55db
 Database  MySQL Datebase
 A means of communication of upper machine  TCP/ IP Protocol
 Data output   EXCEL 2003, 2010, TXT
 Server disc configuration  500GB
 Communication interface  Internet access
 Server operating system  Windows 7
 Leak current  <5 μA
 Per unit main channel qty  80
 Clamp  Alligator clamp, polymer clame, ring clamp optional
 Dimension  L483 * W404 * H1300mm




1 year warranty with lifetime support. Man-made damage is not covered.
