Product Details:
Place of Origin: Shenzhen, China
Brand Name: TICO
Model Number: STC-DTH300
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Standard export wooden package
Delivery Time: 5~8 working days
Payment Terms: T/T
Supply Ability: 200 Set per month

Touch Screen Controlled 300mm Film Coating Machine With Bottom Heating Device

Description
Operation: Touch Screen Controlled Heating Method: Bottom Heating
Vacuum Pump: Built-in Type Heating Temp: Max 150℃ Adjustable
Power Supply: AC110/220V Optioal Coating Speed: 0~200mm/s Adjustable
High Light:

AC110V Film Coating Machine

,

300mm Film Coating Machine

,

Electrode Film Battery Coating Machine

Bottom Heating 300mm Film Coating Machine



Product Details



STC-DTH300 is a compact electrode film coating machine with vacuum chuck which used in all kinds film coating research, like ceramic films, crystal film, lithium battery electrode, etc. It is designed with bottom heating, the heating temperature up to 150℃ adjustable and digital display.



Key Features



• Touch screen operation, high automation.

• Vacuum aluminum chuck is designed for quickly suction of substrate.

• 300mm length max coating stroke, and 0~200mm/s coating speed can be set, excellwnt working efficiency.

• Bottom heating, the heating temperature up to 150℃ adjustable and digital display.

• Built-in type vacuum, high integration.



Technical Parameters



 Model  STC-DTH300
 Power supply  AC110/220V optioal
 Max coating stroke length  300mm adjustable customized size is available
 Doctor blade  100mm fixed width &adjustable width optional
 Coating thickness range  0.01~3.5mm adjustable
 Vacuum chuck  L415 * W200 * H30mm
 Vacuum pump  Internal
 Coating speed  0~200mm/s adjustable
 Dimension  L500 * W310 * H200mm
 Weight  40kg



Warranty



1 year warranty with lifetime support. Man-made damage is not covered.



FAQ



1. Are you a manufacturer?



A: Yes, our factory is located in Shenzhen, China.
We have more than 10 year experience for manufacturing battery lab research equipment. We own a professional R&D department.



2. Do you accept customized product?

A: Yes. Most of our products can be customized to meet different requirements.



3. Will you provide test video before dispatch?

A: Yes, we take test video for every equipment before dispatch, which will display how to use it.



4. Can you offer overseas installation service?

A: Yes, we can dispatch professional engineer for on-site installation service.
