Product Details:
|
| Features: | Multi-purpose | Key Character: | 4*5L Large Grinding Container |
|---|---|---|---|
| Mill Container: | Different Milling Container Is Optional | Appearance: | Square-shape |
| Working Voltage: | AC380V, 50Hz | Volumae Of Container: | 5L/ Container, Total 20L |
| High Light: | 20L Ball Milling Machine,Planetary Ball Milling Machine,50Hz Planetary Ball Mill |
||
20L Planetary Ball Milling Machine
Product Introduction
STC-XQM20 planetary ball milling machine is widely used in many fields, like geology, mine, metallurgy, electric industry, construction, chemicals, light industry, medicine, etc. Different meterial of milling jar is optional according to the milling material.
Key Features
• Stable rotating speed of the gear transmission ensure the consistency and repeatability of the experiment.
• Planetary movement principle is adopted, with features of high speed, high efficiency, small geanualrity.
• 4 milling containers design allows 4 different materials can be milled at the same time.
• Rotating speed is adjustable by frequency conventer.
• With functions of timing power off, self-time forward and reverse rotating, one-way direction milling, alternation milling, continuous milling.
• Different material of milling jar & balls can be optional.
Technical Parameters
| Model | STC-XQM20 |
| Working voltage | AC380V, 50Hz |
| Volumae of container | 5L/ container, total 20L |
| Container qty | 4 pcs |
| Transmission mode | Gear driven |
| Working mode | 2 or 4 containers can be used each time |
| Max loading | 2/3 of milling container |
| Feeding material |
Soft and crispy mateial ≤10mm, Other mateial ≤3mm |
| Output granularity | Min reach to 0.1μm |
| Motor power | 4KW |
| Max continuous working time | 75hrs |
| Total running time setting | 1~9999 min |
| Alternating running time of forward & reverse rotation | 1~999 min |
| Speed |
Revolution: 25~215 rpm Totation: 50~430 rpm |
| Noisy | 68±5db |
| Dimension | L1200 * W750 * H920mm |
| Weight | 330kg |
Warranty
1 year warranty with lifetime support. Man-made damage is not covered.
FAQ
1. Are you a manufacturer?
A: Yes, our factory is located in Shenzhen, China.
We have more than 10 Year experience for manufacturing battery lab research equipment. We own a professional R&D department.
2. Do you accept customized product?
A: Yes, most of our products can be customized to meet different requirements.
3. Will you provide test video before dispatch?
A: Yes, we take test video for every equipment before dispatch, which will display how to use it.
4. Can you offer overseas installation service?
A: Yes, we can dispatch professional engineer for on-site installation service.
