| Brand Name: | TICO |
| Model Number: | STC-KZK-3D |
| MOQ: | 1 Set |
| Price: | Negotiable |
| Delivery Time: | 5~8 working days |
| Payment Terms: | T/T |
3 Layers High Vacuum Degree Drying Oven
Product Details
The oven inner chamber is made iof stainless steel, and each working chamber runs independently. Automatic cycle for heating, vacuuming, and gas filling. It adopts PLC &Touch screen control system with high automation. Flow blast for heating & dissipation quickly. Great performance in pressure holding.
Key Features
• 3 layers stainless steel inner chamber with 3mm thickness, anti-resistance and durable.
• The device is equipped with unoversal movable casters for moving easily.
• The equipped adopts 304 stainless steel heating tube coiled inside the heating type, uniform temperature control, the device has been monitored at 80℃, 100℃, 120℃ and other temperature monitoring points to monitor the temperature before delivery.
• The equipped is sealed with silicone rubber seals, 15mm thick tempered glass door, each door is designed with an observation windows.
• Side-door designed. Two stainless steel brackets in each chamber are devided into 3 layers (layer height 103mm).
Technical Parameters
| Model | STC-KZK-3D |
| Voltage | AC380V, 50Hz |
| Power | 12KW |
| Over temp | RT~150℃ adjustable |
| Inner liner dimension | W660 * D900 * H330mm |
| Heating time | ≤35min, RT~85℃ (No load) |
| Over surface temp | RT±10℃ (when working temp at 85℃) |
| Inner chamber material | 3mm thickness SUS 304 stainless steel |
| Inner chamber temp error | ±2℃ (No loading in vacuum state) |
| Protection function | Automatic power failure protection; Automatic over-temp alarm |
| Vacuum holding time | Gas leakage rate 20Pa/h evenly within 24h |
| Vacuum degree | ≤10Pa |
| Dimension | W1410 * D1500 * H1900 |
| Weight | 1200kg |
Warranty
1 year warranty with lifetime support. Man-made damage is not covered.
FAQ
1. Are you a manufacturer?
A: Yes, our factory is located in Shenzhen, China.
We have more than 10 Year experience for manufacturing battery lab research equipment. We own a professional R&D department.
2. Do you accept customized product?
A: Yes, most of our products can be customized to meet different requirements.
3. Will you provide test video before dispatch?
A: Yes, we take test video for every equipment before dispatch, which will display how to use it.
4. Can you offer overseas installation service?
A: Yes, we can dispatch professional engineer for on-site installation service.
|
|
