Product Details:
|
| Sealing Blade Length: | 200mm | Sealing Width: | 5mm, Customized Size Is Available |
|---|---|---|---|
| Chamber Inner Dimension: | L325mm*W220mm*H170mm | Chamber External Dimension: | L500mm*W350mm*H630mm |
| Electric Box Dimension: | L560mm*W220mm*H340mm | Gas Consumption: | ≈0.2L Compressed Gas Per Sealing |
| High Light: | Electrolyte Standing Pouch Cell Assembly Equipment,AC220V Pouch Cell Assembly Equipment,5mm Pouch Cell Lab Equipment |
||
2-In-1 Battery Electrolyte Standing & Hot Pre-sealingh for Pouch Cell R&D
Product Introduction
STC-JY2200 is a multi-functional pouch cell machine, it can carry out the vacuum standing & hot pre-sealing process for pouch battery.
Features
Technical Parameter
| Model | STC-BYJ2200 |
| Voltage | AC220V/AC110V optional |
| Power | 500W heating tube. When heating the power consumption is 1000W |
| Vacuum degree | above -0.095Mpa |
| Vacuum standing time | 0~9999s adjustable, pressure adjustable |
| Sealing temperature | RT~250℃ adjustable |
| Temperature accuracy | ±2℃ adjustable |
| Hot sealing time | 0~99s adjustable |
| Hot sealing pressure | 0~6Kg/cm2 adjustable |
| Sealing blade length | 200mm, customized size is available |
| Sealing width | 5mm, customized size is available |
| Chamber inner dimensio | L325mm*W220mm*H170mm |
| Chamber external dimension | L500mm*W350mm*H630mm |
| Electric box dimension | L560mm*W220mm*H340mm |
| Compressed air | 0.5~0.7Mpa, when used in glovebox, the gas must be same with glovebox working gas |
| Gas consumption |
≈ compressed gas per sealing |
| Weight | 70kg |
Warranty
1 year warranty with lifetime support. Man-made damage is not covered.
Working Details
FAQ
1. Are you a manufacturer?
A: Yes, our factory is located in Shenzhen, China.
We have more than 10 year experience for manufacturing battery lab research equipment. We own a professional R&D department.
2. Do you accept customized product?
A: Yes. Most of our products can be customized to meet different requirements.
3. Will you provide test video before dispatch?
A: Yes, we take test video for every equipment before dispatch, which will display how to use it.
4. Can you offer overseas installation service?
A: Yes, we can dispatch professional engineer for on-site installation service.
