Semi-auto Battery Electrode Slitting Machine With Unwinding Mechanism

Name: Semi-auto Battery Electrode Slitting Machine With Unwinding Mechanism
Brand: Shenzhen TICO Technology Co.,Ltd.
SKU: STC-CFT-D300S
Price: 1,500.00 USD
Availability: InStock

Brand Name:	TICO
Model Number:	STC-CFT-D300S
MOQ:	1 set
Price:	Negotiable
Delivery Time:	8~15 working days
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Shen Zhen

Product Name:

Cylindrical Battery Electrode Slitter

Power:

200W

Slitting Width:

Standard Is Combined Die For 56mm & 58mm, Customized Size Is Available From 20~300mm

Slitting Thickness:

80~300μm Battery Electrode

Slitting Speed:

Max 4m/min, It Is Adjustable

Weight:

100kg

Packaging Details:

Standard export wooden packing

Supply Ability:

20 sets per month

Highlight:

200W Electrode Slitting Machine

Battery Electrode Slitting Machine

Unwinder Cylindrical Cell Lab Equipment

Product Description

Semi-auto Battery Electrode Slitting Machine with Unwinding Mechanism

Brief Introduction

STC-CFT-D300S semi-auto slitter is used for lab battery electrode slitting. The standard slitting width is 56 &58mm, customized size form 20~300mm is available. It is desktop, easy operation

Key Features

● Unwinding mechanism device are equipped.

● Slitting speed is adjustable.

● Protection cover is designed for safety operation.

● The die total width 300mm, slitting width can be made according to requirement.

● Slitting no burr, no powder drop.

● It is a desktop, saving space in lab.

Techinial Parameter

Model	STC-CFT-D300S
Working voltage	AC110V/220V optional
Power	200W
Slitting width	Standard is combined die for 56mm & 58mm, Customized size is available from 20~300mm
Slitting thickness	80~300μm battery electrode
Slitting burr	≤ 25μm
Slitting speed	Max 4m/min, it is adjustable
Dimension	L850 * W920 * H400mm
Weight	100kg

Warranty

1 year warranty with lifetime support. Man-made damage is not covered.

FAQ

1. Are you a manufacturer?

A: Yes, our factory is located in Shenzhen, China.
We have more than 10 Year experience for manufacturing battery lab research equipment. We own a professional R&D department.

2. Do you accept customized product?

A: Yes. Most of our products can be customized to meet different requirements.

3. Will you provide test video before dispatch?

A: Yes, we take test video for every equipment before dispatch, which will display how to use it.

4. Can you offer overseas installation service?

A: Yes, we can dispatch professional engineer for on-site installation service.
