Product Details:
|
| Power Supply: | AC220V | Power: | 0.5KW |
|---|---|---|---|
| Application: | Φ60 Batteries & Supercapacitors | Requirements For The Load At The Installation Site: | 0.5T/m2 Or Above |
| Weight: | 300kg | Air Source: | 0.5~0.8MPa |
| High Light: | Core To Can Insert Machine,Supercapacitor Battery Can Insert Machine,Supercapacitor Cell to Case Insert Machine |
||
Supercapacitor Cell to Case Insert Machine
Product Introduction of Battery Core into Can Machine
It is used to press supercapacitors (after the welded cell is assembled with O-ring of the upper cover) into the case and fasten the O-ring to the inner seal.
Technical parameter for Supercapacitor Core into Case Equipment
| Model | STC-RK60 |
| Voltage | AC220V, 50Hz |
| Power | 0.5Kw |
| Application | Φ60 batteries and supercapacitors, with a length of H50~150mm can be customized |
| The depth in the shell | Adjustable |
| Accuracy of the depth in the case | ±0.1mm |
| Speed of pressing into the case | 50mm/s, adjustable |
| Service life of the tolling and mold | ≥5 000 000 times |
| Capacity | ≥3 pcs |
| Utilization rate | 98% |
| Air source | 0.5~0.8MPa |
| Weight | 300kg |
| Working dimensions | L700 * W500 * H1980mm |
| Transportation dimensions | L700 * W500 * H1750mm |
Key features
1. The high-precision guide post and sleeve are used to ensure the stable dimensions in the case.
2. The supercapacitor height can be adjusted to suit different products.
3. The counting function is conductive to viewing the processing quantity.
4. The cylinder speed is even and adjustable.
5. The light curtain is used for electronic protection to ensure the safe and reliable use.
6. The external geometry is exquisite and neat.
7. The PLC control and HMI are conducive to simple operation.
8. The high-frequency heating is optional for the interference fit between the case and positive current collector.
Warranty
1 year warranty with lifetime support. Man-made damage is not covered.
FAQ
1. Are you a manufacturer?
A: Yes, our factory is located in Shenzhen, China.
We have more than 10 Year experience for manufacturing battery lab research equipment. We own a professional R&D department.
2. Do you accept customized product?
A: Yes, most of our products can be customized to meet different requirements.
3. Will you provide test video before dispatch?
A: Yes, we take test video for every equipment before dispatch, which will display how to use it.
4. Can you offer overseas installation service?
A: Yes, we can dispatch professional engineer for on-site installation service.
