Product Details:
|
| Model: | STC-SEF-60 | Power: | 0.5Kw |
|---|---|---|---|
| Weight: | 0.5T | Capacity: | ≥3 Pcs |
| Utilization Rate: | 98% | Working Temperature: | 15~30℃ |
| High Light: | Supercapacitor Battery Secondary Assembly Equipment,Secondary Assembly Supercapacitor Battery Equipment,Supercapacitor Battery Secondary Crimping Machine |
||
Supercapacitor Battery Secondray Assembly Equipment for Manufacturing Line
Production Introduction for Secondary Crimping Machine
It is suitable for secondary molding, sealing and crimping of battery and supercapacitor cases.
Key Features for Secondard Sealing Equipment
● The annular jacket of mold designed for sealing process, good performance in sealing.
● High precision mold of guide post and sleeve, ensuring the parallelism of the upper and lower molds.
● The mold is controlled by the pressure cylinder to seal cases to ensure the stable output.
● Sealing height, sealing pressure and holding time is adjustable
● PLC control system, high stable and reliable, easy to operate.
● The color LCD touch screen, easier to view parameters.
Technical Parameters for Supercapacitor Secondly Sealing Machine
| Model | STC-SEF-60 |
| Voltage | AC220V, 50Hz |
| Power | 0.5Kw |
| Application | Φ60 battery and supercapacitor cells, with a length of H50~150mm can be customized |
| Dimensional change of the side of the sealed cased | ≤±0.03mm |
| Capacitor height accuracy after sealing | HA≤0.1mm |
| Flange | Sealed with a mold |
| Service life of the tooling and mold | ≥5000000 times |
| Capacity | ≥3 pcs |
| Ultilization rate | 98% |
| Air source | 0.5~0.7 MPa adjustable |
| Air consumption | 0.4m3/min |
| Working dimensions | L650 * W600 * H2150mm |
| Transportation | L650 * W600 * H1900mm |
| Weight | 500kg |
Warranty
1 year warranty with lifetime support. Man-made damage is not covered.
FAQ
1. Are you a manufacturer?
A: Yes, our factory is located in Shenzhen, China.
We have more than 10 Year experience for manufacturing battery lab research equipment. We own a professional R&D department.
2. Do you accept customized product?
A: Yes, most of our products can be customized to meet different requirements.
3. Will you provide test video before dispatch?
A: Yes, we take test video for every equipment before dispatch, which will display how to use it.
4. Can you offer overseas installation service?
A: Yes, we can dispatch professional engineer for on-site installation service.
