| Brand Name: | TICO |
| Model Number: | STC-XQM-12A |
| MOQ: | 1 Set |
| Price: | USD 2000~3500 |
| Delivery Time: | 5~7 days |
| Payment Terms: | T/T |
12L Planetary Ball Milling Machine Laboratory Multi Application
12L Capacity Planetary Ball Milling Machine
Product Introduction of Planetary Powder Material Milling Equipment
STC-XQM-12A planetary ball milling machine is a laboratory multi-application powder material milling equipment, which is widely used in many fields, like geology, mine, metallurgy, electric industry, construction, ceramics, chemicals, light industry, medicine, etc. Different material of milling jar is optional according to the milled mateial.
Technical Parameter of Planetary Ball Miller
| Model | STC-XQM-12A |
| Voltage | AC220V, 50Hz |
| Volume of container | 1~3L/ conatiner, max 12L |
| Contianer qty | 4 pcs |
| Transmission mode | Gear driven |
| Working mode | 2 or 4 containers can be used each time |
| Max loading | 2/3 of miling container |
| Feeding material | Min reach to 0.1μm |
| Motor power | 1.5KW |
| Max continuous working time | 72 hrs |
| Total running time setting | 1~9999 min |
| Alternating running time of forward &reverse rotation | 1~999 min |
| Speed |
Revolution: 35~290 rpm |
| Noise | 60±5db |
| Dimenson | L880 * W560 * H670mm |
| Weight | 132kg |
Features of Our Planetary Ball Milling Machine
(1) Stable rotating speed of the gear transmission ensures the consistency and repeatability of the experience.
(2) Planetary movement principle is adopted, with features of high speed,, high efficiency, small granularity.
(3) 4 milling containers design allows 4 different materials can be milled at the same time.
(4) Rotating speed is adjustable by frequency converter.
(5) With functions of timing power off, self-timing forward and reverse rotating, one-way direction milling, alternation milling, continuous milling.
(6) Different material of milling jar & balls can be optional.
SHENZHEN TICO TECHNOLOGY CO., LTD
(1) Total solution for Lithium-ion Battery R&D.
(2) One-stop service in designing, manufacturing and marketing of battery equipment &material.
(3) An integrated company of industry &trade.
Warranty
1 year's warranty with lifetime support.
FAQ
1. Are you a manufacturer?
TICO: Yes, our factory is located in Shenzhen, China.
We have more than 10 Year experience for manufacturing battery lab research equipment. We own a professional R&D department.
2. Do you accept customized product?
TICO: Yes, most of our products can be customized to meet different requirements.
3. Will you provide test video before dispatch?
TICO: Yes, we take test video for every equipment before dispatch, which will display how to use it.
4. Can you offer overseas installation service?
TICO: Yes, we can dispatch professional engineer for on-site installation service.
|
|
