Plunger Pump Slurry Feeding Device for Slot Die Film Coating Machine

Name: Plunger Pump Slurry Feeding Device for Slot Die Film Coating Machine
Brand: Shenzhen TICO Technology Co.,Ltd.
SKU: STC-EZSB-A
Price: 2,499.30 USD
Availability: InStock

Brand Name:	TICO
Model Number:	STC-EZSB-A
MOQ:	1 Set
Price:	Negotiable
Delivery Time:	3~5 days
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen, China

Certification:

Model:

STC-EZSB-A

Power:

120W

Feeding Speed:

0.05~5mm/s (propulsion Speed Of Syringe Piston)

Syringe Volume:

20ml, 30ml, 50ml Are Equipped As Standard

Piple Line:

Teflon Pipe, External Diameter 3.2mm, Inner Diameter 1.6mm

Stroke:

Max. 100mm

Packaging Details:

Standard export wooden box package

Supply Ability:

120 sets per month

Highlight:

120W Battery Coating Machine

30ml Battery Coating Machine

120W Slurry Feeding Device

Product Description

Plunger Pump Slurry Feeding Device for Slot Die Film Coating Machine

Brief Introduction

This product is specifically designed to supply slurry to the slot die film applicator in vacuum film coating machine, ensuring consistent and reliable flow for uniform coating quality.

Key Features

● Stepping motor control the speed of the screw rod, the flow can be adjusted to match the flow required by the coating machine.

● This machine can pause instantly, which can ensure no slurry leakage, decrease the maintain process.

● Syringes size is optional, convenient for replacement.

● It can be used in conjunction with the coating.

● Exquisite appearance, easy to maintain.

Technical Parameters

Model	STC-EZSB-A
Voltage	AC100~240V±10%, 50/60Hz
Power	120W
Feeding speed	0.05~5mm/s (propulsion speed of syringe piston)
Syringe volume	20ml, 30ml, 50ml are equipped as standard
Syringes material	PP material
Pipeline	Teflon pipe, external diameter 3.2mm, inner diameter 1.6mm
Stroke	Max. 100mm
Driven mode	Stepping motor
Applicator	Used with coating machine
Dimension	L400 * W200 * H230mm
Weight	8kg

Warranty

1 year warranty with lifetime support.

FAQ

1. Are you a manufacturer?

TICO: Yes, our factory is located in Shenzhen, China.

We have more than 10 Year experience for manufacturing battery lab research equipment. We own a professional R&D department.

2. Do you accept customized product?

TICO: Yes, most of our products can be customized to meet different requirements.

3. Will you provide test video before dispatch?

TICO: Yes, we take test video for every equipment before dispatch, which will display how to use it.

4. Can you offer overseas installation service?

TICO: Yes, we can dispatch professional engineer for on-site installation service.
