Product Details:
|
| Material: | SS 630 Stainless Steel | Coating Thickness: | Max. 5mm |
|---|---|---|---|
| Micrometer Accuracy: | 1μm | Dimension: | L170 * W90 * H110mm |
| Weight: | 2kg | ||
| High Light: | Slot Die Film Applicator,1μM Stainless Steel Applicator,SS630 Film Applicator |
||
SS630 Stainless Steel Slot Die Film Applicator 1μM Micrometer Accuracy
Slot Die Film Applicator
Product Introduction of Slot Die Film Applicator
It is used for film coating on sheet-type substrate surface. It is compatible with slot extrusion coating and doctor blade coating. It can be used for a wide range of film coating research, such as battery material film, OLED, solar photoelectric film &polymer conductive film, etc.
Product Specifications
| Model | STC-JTM100 | |
| Material | SS 630 stainless steel | |
| Coating way | Slot die coating | Blade coating |
| Accuracy | Lip straightness≤4μm | Straightness≤4μm |
| Die chamber volume | 2.6ml | / |
| Coating width | Max. 100mm, “C” type opening, customized size is available | 150mm |
| Micrometer accuracy | 1μm | 1μm |
| Coating thickness | 5mm | 5mm |
| Dimension | L170 * W90 * H110mm | |
| Weight | 2kg | |
Key Features
(1) It is compatible with slot extrusion coating and doctor blade coating. (Battery slurry feeding device is required for slot die film coating)
(2) Wide application range, high coating accuracy.
(3) The coating is sealed during extrusion coating, which is less affected by environment.
(4) It adopts anti-corrosion material, long lifetime.
(5) Smaller size, operation conveniently.
