Large Image :  Pouch Cell Penumatic Trimming Mahcine For Battery Al - Laminated Case

Product Details:
Place of Origin: Shenzhen, China
Brand Name: TICO
Certification: CE
Model Number: STC-BQB200
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Standard export wooden box package
Delivery Time: 3~5 days
Payment Terms: T/T
Supply Ability: 300 sets per month

Pouch Cell Penumatic Trimming Mahcine For Battery Al - Laminated Case

Description
Model: STC-BQB200 Voltage: AC220V
Working Speed: 10 Pcs/min Trimming Length: 200mm
Trimming Width: 2.5~8mm Adjustable Air Source: 0.5~0.7MPa
High Light:

Pouch Cell Penumatic Trimming Mahcine

,

Penumatic Trimming Mahcine For Battery Case

Pouch Cell Al-laminated Cup Edges Trimming Machine

Pouch Cell Penumatic Trimming Mahcine For Battery Al-Laminated Case



Product Details of Trimming Mahcine



It is used for pouch cell cup edges trimming after pouch cell Al-laminated film forming.



Technical Parameters of Al-laminated Box Edges Cutting Machine



 Model  STC-BQB200
 Voltage  AC220V, 50Hz
 Working speed  10pcs/min
 Trimming length  200mm
 Trimming width  2.5~8mm adjustable
 Air source  0.5~0.7MPa
 Dimension  L320 * W160 * H340mm
 Weight  40kg



Key Features of Hot Sealing Machine



Cylinder driven, high precision in cutting process.

Edges cutting width is adjustable in 2.5~8mm.

Cutting blade is made of high-speed steel, the blade is sharp.

Foot switch controlled, more safety during operation.



Warranty



1 year warranty with lifetime support. Man-made damage is not covered.
