| Brand Name: | TICO |
| Model Number: | STC-SJH-60 |
| MOQ: | 1 Set |
| Price: | Negotiable |
| Delivery Time: | 3~7 Workjng days |
| Payment Terms: | T/T, L/C |
60138 Supercapacitor Laser Welding Machine
1000W Industry Laser Welding Machine For 60138 Supercapacitor
Product introduction of laser welder
It is used for 60138 Supercapacitor laser welding.
Key Features
(1) The Optical fiber laser has the advantage of high welding fusion depth& strength.
(2) It can be equipped with multi-axis motion platform and rotary clamp or mechanical arm for welding according to requirement.
(3) Widely applications in various products.
(4) Intelligence operation mode, easy and convenience.
Technical Parameters
| Voltage | AC220V±10% / 380V |
| Output power | 1000W |
| Laser | Continuous fiber laser machine |
| Laser wavelength | 1080nm±5nm |
| Laser mode | Single mode continuous |
| Welding model | Pulse spot-welding, continuous welding |
| Power setting range | 10~100% |
| Power stability | ±2% |
| The dia. of the transmission fiber core | 50μm as standard, 100μm is optional |
| Minimum facula | 0.2mm |
| Fiber length | 10m as standard, 15m length can be customized |
| Working stroke | 1000*400*500mm standard triaxial, (4-axis, 5-axis is optional) |
| Cooling path | External water cooling |
| Working environment | Clean and dustless, no vibration Temperature range: 13~28℃; Humidity: 5~10% |
| External robotization interface | Can be customized according to requirement |
| Power consumption | 4.5KW |
| Consumables | Protective lenses, water, electric, Ar gas(compressed air) |
Warranty
1 year warranty with lifetime support. Man-made damage is not covered.
We can also supply:
1.) full set of lithium battery materials,including :
LiMn2O4,LTO,LiNiMnCoO2(NMC),LiCoO2,Graphite(MCMB)and other cathode&anode battery materials;Alumimun foil,copper foils,battery separator,etc.
2. )full set of lithium battery equipments,for example:
Mixing machine --coating machine--oven--rolling machine--welding machine--slitting / cutiing machine --winding machine--sealed machine,etc.
3.) full set of lithium battery technology:
We can design the laboratory and production line,according to customer's request.
FAQ
1. Are you a manufacturer?
Tico: Yes, our factory is located in Shenzhen, China.
We have more than 10 Year experience for manufacturing battery lab research equipment. We own a professional R&D department.
2. Do you accept customized product?
Tico: Yes, most of our products can be customized to meet different requirements.
3. Will you provide test video before dispatch?
Tico: Yes, we take test video for every equipment before dispatch, which will display how to use it.
4. Can you offer overseas installation service?
Tico: Yes, we can dispatch professional engineer for on-site installation service.
|
|
