Product Details:
|
| Features: | Internal Of Things | Product Name: | 4 Working Station Vacuum Glove Box |
|---|---|---|---|
| Application: | Laboratory | Application Industry: | Lithium Battery, Physical Chemistry, OLED&PLED, Organometallic, Fine Chemicals, Etc |
| High Light: | Laboratory High Vacuum Glovebox,4 Working Stations Vacuum Glovebox |
||
Laboratory High Vacuum 4 Working Stations Glovebox IOT Vacuum Glove Box
4 Working Stations High Vacuum Glovebox
Product introduction of IOT Vacuum Glovebox
4 working stations, opposite operation, integrated with single-column purification unit, PLC control and touch screen operation, vacuum pump, bracket, a closed box, with inclined operation surface and removable safety glass front window. Under standard conditions, i.e. constant temperature of 20℃, one standard atmospheric pressure, 99.999% inert gas source, water and oxygen index less than 1 ppm.
Key Features
(1) Intelligent analysis & pre-warning of equipment conditions, the abnormal alarm message is actively sent, troubleshooting remotely and debugging online.
(2) H2O &O2<1ppm.
(3) This machine owns the advantage of low leakage rate.
(4) PLC control, and Color Touchscreen HMO, Automatic purge; Circulation; Regeneration; Pressure control; User Friendly Interface.
(5) It is widely applied in lab battery research and development.
(6) Various of famous brand components in the world are used in this glovebox.
(7) Two parts, two work stations.
Technical Parameters
| Box | |||
| Box | Material | 304 Stainless steel;
Thickness: 3mm
|
|
| Outside surface | White | ||
| Windows | Inclined window, transparent tempered safety glass;
Thickness: 8mm
|
||
| Glovebox ports | Aluminum alloy;
O-ring sealed
|
||
| Gloves | Butyl rubber;
Thickness: 0.4mm;
Dia.: 8 inches; Length: 32 inches |
||
| Filter | 0.3 micron; 1 gas inlet and 1 gas outlet | ||
| Shelves | Stainless steel, 2 layers | ||
| Box light | Installed above the front of each glass window | ||
| Big antechamber | |||
| Size | φ360xL600mm | ||
| Material | 304 stainless steel | ||
| Surface | Brushed finish inside and white painted color outside | ||
| Accessories | Slide bracket | 304 SS | |
| Door | Two doors;
Aluminum alloy;
Thickness: 10mm;
External swing door, internal door lifting structure
|
||
| Manometer | Analog display | ||
| Control | The electromagnetic valve touch screen operates automatically, completing the operation of the big antechamber with one button, it automatically vacuuming and replenishing air three times. | ||
| Mini antechamber | |||
| Chamber |
Inside dimension | φ150xL300mm,the length of the part entering the box is 100mm | |
| Material | φ150xL300mm,the length of the part entering the box is 100mm | ||
| Surface | φ150xL300mm,the length of the part entering the box is 100mm | ||
| Accessories | Door | 2 doors | |
| Manometer | Analog display | ||
| Control | Manual operation button | ||
Purification column |
Function | Removal of H2O and O2 | |
| Container material | 304 Stainless steel | ||
| Absorber unit | Copper catalyst: 5 Kg;
Molecular sieve: 5 Kg
|
||
| Capacity of purifying | Removal of O2: 60L;
Removal of H2O: 2kg
|
||
| H2O and O2 | Less than 1ppm | ||
| Circulation system | Working gas | Nitrogen, Argon | |
| Circulation capacity | Integrated fan flow 90m3/h, automatic frequency conversion be set according to water and oxygen conditions | ||
| Regeneration | Operation | PLC automatic control regeneration process | |
| Regeneration gas | Working gas and H2 mixture(H2:5~10%) | ||
| Vacuum pump | Type | 12m3/h, Rotary vane pump, with oil mist filter | |
| Valves | Main valves: DN 40 KF electric angle valve Angle valves |
||
| Controlling systrem | |||
| Functions | Including self-diagnosis, power-off and startup features, with pressure control and adaptive functions; Automatic control, cycle control, password protection; The unit control adopts Siemens PLC touch screen. | ||
| Pressure control | The pressure working pressure of the control box and transition chamber can be set freely within+/- 15 mbar, and the system will automatically protect the pressure exceeding+/- 16 mbar; | ||
| Oxygen analyzer | Measuring range of 0~1000ppm ZrO2 oxygen solid sensor, long life, to be exposed in the air without any consumption. |
||
| Moisture analyzer | Measuring Range: 0～1000ppm | ||
| Solvent absorber | Purification system, internal installed ,fill about 2kg of active carbon,φ136xH256mm, rapid material replacement, and do not damage the high-purity atmosphere | ||
| IOT system | (1) Mobile terminal adaptive control system (you can log in to the control system by scanning QR code, WeChat official account or downloading and installing APP), which supports multiple browser access.
(2) The equipment status data is recorded in real time, and the historical data can be queried.
(3) Real-time monitoring of equipment operation status.
(4) Online after-sales service, providing remote diagnosis and debugging.
(5) Actively remind the equipment of abnormal status (WeChat, SMS or email).
(6) Online customer service and self-help troubleshooting.
|
||
Warranty
1 year warranty with lifetime support. Man-made damage is not covered.
We can also supply:
1.) full set of lithium battery materials,including :
LiMn2O4,LTO,LiNiMnCoO2(NMC),LiCoO2,Graphite(MCMB)and other cathode&anode battery materials;Alumimun foil,copper foils,battery separator,etc.
2. )full set of lithium battery equipments,for example:
Mixing machine --coating machine--oven--rolling machine--welding machine--slitting / cutiing machine --winding machine--sealed machine,etc.
3.) full set of lithium battery technology:
We can design the laboratory and production line,according to customer's request.
FAQ
1. Are you a manufacturer?
Tico: Yes, our factory is located in Shenzhen, China.
We have more than 10 Year experience for manufacturing battery lab research equipment. We own a professional R&D department.
2. Do you accept customized product?
Tico: Yes, most of our products can be customized to meet different requirements.
3. Will you provide test video before dispatch?
Tico: Yes, we take test video for every equipment before dispatch, which will display how to use it.
4. Can you offer overseas installation service?
Tico: Yes, we can dispatch professional engineer for on-site installation service.
