| Brand Name: | TICO |
| Model Number: | STC-CGC-V18 |
| MOQ: | 1 Set |
| Price: | Negotiable |
| Delivery Time: | 20~25 working days |
| Payment Terms: | T/T |
Vertical Grooving Die Cylindrical Cell Grooving Machine for Lithium Making
Brief Introduction
STC-CGC-V18 is the new generation of cylindrical cell grooving machine from TICO. Huge adjustments have been made in the position of the grooving die, from horizontal to vertical placement, and this adjustment produces a more stable battery. There are various sizes of grooving dies as options for users, like 18650, 26650, 21700, 32650. In addition, the grooving die has been upgraded to a service lifetime of 1,000,000 times. This machine is suitable for uniform automatic grooving of cylindrical steel cases (or capacitor aluminum cases). It is a perfect device for cylindrical research for battery lab or factory trial production.
Features
● Vertical grooving dies structure, the spacer is not easy to be dropped out.
● Adjustable groove size, high precision and stable size.
● Groove processing of different kinds of cylindrical cells is available.
● The machine is compact in size, delicate and nice in appearance, and easy to operate.
● PLC touch screen setting is easily operated.
Technical Parameters
| Model | STC-CGC-V18 |
| Product placement method | Vertical |
| Power supply | AC220V, 50HZ |
| Power | 220W |
| Grooving die (steel case) |
18650 grooving die as standard, other size grooving die is optional (26650,21700,32650...) |
|
Aluminum case capacitor groove |
≤Φ30mm |
|
Grooving depth |
1.2~2.0mm (adjustable) |
|
Grooving width |
1.1~1.5mm(according to grooving die thickness) |
|
Processing precision |
±0.1mm |
|
Grooving die lifetime |
> 1000 000 times |
|
Production output |
400EA/H(semi-automatic) |
|
Air source |
0.5MPa~0.7MPa |
|
Dimension |
L420 * W370 * H550mm |
|
Weight |
50kg |
Warranty
1 year warranty with lifetime support. Man-made damage is not covered.
FAQ
1. Are you a manufacturer ?
A: Yes, our factory is located in Shenzhen, China.
We have more than 10 years experience for manufacturing battery lab research equipment. We owns a professional R& D department.
2. Do you accept customized product ?
A : Yes. Most of our products can be customzied to meet different requirements.
3. Will you provide test video before dispatch ?
A : Yes, we take test video for every equipment before dispatch, which will display how to use it.
4. Can you offer overseas installation service ?
A : Yes, we can dispatch professional engineer for on-site installation service.
|
|
