| Brand Name: | TICO |
| Model Number: | STC-EXJ-5L |
| MOQ: | 1 Piece |
| Price: | Negotiable |
| Delivery Time: | 5~8 working days |
| Payment Terms: | T/T, |
5L Lab Planetary Vacuum Mixer and Dispersing Machine
Brief Introduction
STC-EXJ-5L is suitable for mixing and dispersing the powder and liquid of various common types of batteries, and finally obtains evenly mixed battery slurry, and is also very suitable for high-viscosity technical processes. The maximum volume of the equipment is 5L. Viscosity range adapted to operating conditions ≤ 1200000 cP.
Key Features
● Vacuum environment, effectively eliminating air bubbles generated by the mixing process, good vacuum holding effect.
● Jacketed mixing bucket design, can be filled with cooling water, suitable for various process requirements.
● Form of jacket for temperature adjustment, the single-layer jacket for bucket wall is used for cooling or heating; and the single-layer jacket for bucket bottom is used for cooling or heating.
● Over temperature alarm system, safer and smarter.
● Operation failure stop: the frequency converter is self-provided with overload, overcurrent, overvoltage, leakage of electricity, short-phase protection.
● Variable cross-section Non-prismatic mixing design can make slurry get better mixing effect.
● Touch screen, simple operation, high automation.
Technical Parameters
| Model | STC-EXJ-5L |
| Power supply | AC 3×380V±5﹪, 50Hz |
| Lower bucket component | |
| Design volume | 8L |
| Effective volume | 2.7-5L |
| Bucket material | 304 stainless steel |
| Design ambient temperature | -10～+120°C |
| Mixing component | |
| Mixing power | 1.5KW |
| Speed of mixing propeller | 10-98rpm |
| Diameter of mixing propeller | 124mm |
| Pattern of mixing propeller | Non-prismatic twist type, 90° spiral line |
| Quantity of mixing propeller | 2 pieces |
| Distance between propellers | 7±2mm |
| Dispersed component | |
| Dispersion power | 2.2KW |
| Speed of dispersion | 610-6100rpm |
| Pattern of dispersion disc | Sawtooth pattern |
| Quantity of dispersion disc | 1 piece |
| Material of dispersion disc | 304 stainless steel |
| Wiped-wall component | |
| Material of wiped-wall bracket | 304 stainless steel |
| Material of wiped-wall plate | PTFE |
| Base and lifting component | |
| Material | Carbon steel for high rigid structure |
| Lifting mode | Electric lifting |
| Lifting stroke | ≤290mm |
| Upper bucket component | |
| Material of upper bucket | 304 stainless steel |
| Feeding port of powder |
Quick-open interface DN50 with sight glass one
|
| Feeding port of liquid | One ISO “1/2” quick-open joint |
| Spot-lighting | One DN50 |
| Digital Vacuum Gauge Port | One M14×1.5 inner metric thread interface |
| Vacuum design demand |
Equipped with vacuum system, pumping capacity
2L/S (2XZ-2).
|
| Vacuum holding |
-0.098MPa, it is higher than -0.085MPa after 24
hours holding, without leakage to bucket.
|
| Ground bearing | 900Kg/㎡ |
| Dimension | L1463 * W610 * H1770mm |
| Weight | About 700kg |
Warranty
1 year warranty with lifetime support. Man-made damage is not covered.
FAQ
1. Are you a manufacturer ?
A: Yes, our factory is located in Shenzhen, China.
We have more than 10 years experience for manufacturing battery lab research equipment. We owns a professional R& D department.
2. Do you accept customized product ?
A : Yes. Most of our products can be customzied to meet different requirements.
3. Will you provide test video before dispatch ?
A : Yes, we take test video for every equipment before dispatch, which will display how to use it.
4. Can you offer overseas installation service ?
A : Yes, we can dispatch professional engineer for on-site installation service.
|
|
