One Box One Working Station Glovebox with Single Side Operation
Brief Introduction
STC-VGB-11S is an internet of things vacuum glovebox, centralized equipment management intelligent analysis & early warning of equipment status, the abnormal alarm message is actively pushed, remote fault diagnosis and online debugging. H2O & O2<1ppm. It is widely used for Lithium Battery, Physical Chemistry, OLED&PLED, Organometallic, Solar Cell, Semi-Conductor, Catalyst, Material Handling, Fine Chemicals, Polymeric Materials, Powder Metallurgy, Special Welding, Special Lamps, Nuclear Technology, Pharmaceutical etc.
Key Features
● Intelligent analysis & early warning of equipment status, the abnormal alarm message is actively pushed, remote fault diagnosis and online debugging.
● H2O & O2<1ppm.
● Low leak rate.
● PLC control.
● Wide application.
● World famous brand components are used.
Technical Parameter
| Glovebox House | |
| House | Material: Stainless steel type 304, thickness 3mm |
| Inside surface: Brushed finish | |
| Outside surface: Enameled, white | |
| Inside dimension: L1220 * W750 * H900mm | |
| Window | Safety glass with thin film, thickness 8mm |
| Glove port | Aluminum alloy, O-ring sealed, 2 ports |
| Gloves | 1 pairs; Butyl; thickness 0.4mm; Dia. 8 inches * L32 inches |
| Dust filter | 0.3 micron; 1 gas inlet and 1 gas outlet filter included |
| Stainless shelves | 3 layers mounted inside, height adjustable |
| Box light | LED lamp, front mounted above each window |
| Feedthrough |
DN 40 KF: several pieces for customers’ usage Electric feedthrough: 1 electrical plug for inside(220V) |
| Big Antechamber | |
| Chamber | Inside dimension: φ 360mm * L600mm, right side |
| Material: Stainless steel type 304 | |
| Surface: Brushed finish inside and painted white outside | |
| Accessories | Door: Double door, anodized aluminum |
| Thickness: 10mm | |
| Manometer: Analog display | |
| Control | Manual operation |
| Mini Antechamber | |
| Chamber | Inside dimension: φ150mm * L300mm, right side |
| Material: Stainless steel type 304 | |
| Surface: Brushed finish inside and painted white outside | |
| Accessories | Door: Double door, anodized aluminum |
| Thickness: 10mm | |
| Manometer: Analog display | |
| Control | Manual operation |
| Gas Purification | |
| Purifier | Function: Removal of H2O & O2 |
| Container material: Stainless steel type 304 | |
| Absorber unit: Copper catalyst: 5kg; Molecular sieve: 5kg | |
| Capacity of purifying: Removal of 60L O2 & 2kg H2O | |
| H2O and O2: less than 1 ppm | |
| Gas circulation | Working gas: Nitrogen. Argon and Helium |
| Blower: 90m3/h | |
| Regeneration | Operation: Auto; PLC controlled regeneration |
| Regeneration gas: working gas / H2 mixture (H2: 5~10%) | |
| Pump | Type: 12m3/h Rotary vane pump, oil mist, angle valves, gas ballast control |
| Valves | Main valves: DN 40 KF electro-pneum, angle valves |
| Controlling System | |
| Function | Includes self-diagnosis, electric failure and restart, pressure controlling and self-adapt, circulation controlling, code protection, union controlling adopts, SIEMENS PLC touch screen etc. |
| Pressure controlling | The pressure in the box is controlled by PLC, the pressure can be settled between+/-15mbar,while beyond +/-16mbar the system will automatically protect itself |
| Foot switch | Controlling the pressure, easy to raise or depress the pressure |
| Vacuum system | British EDWARDS vacuum pump, which can be controlled by PLC or by hand. |
| The type is 12m3 /h. It can vacuumize the antechamber and keep the balance of the pressure. | |
| The limit vacuum is ≤ 2x10-1pa. | |
| Analyzer | |
| Moisture analyzer | Measuring range: 0~500ppm, display by PLC |
| Oxygen analyzer | Measuring range: 0~1000ppm, display by PLC |
| Solvent absorber | Absorber unit: activated carbon: 2Kg |
| Connected with main cycle pipeline, the cycled air can go through absorber at first and absorb organic solvent atmosphere | |
| Internet of Things System | |
| Function |
● Login control system from WeChat Public Number ● Login control system by scanning QR code ● Real-time monitoring of device status ● Data backup and historical data query ● Alarm message informed by SMS or Email ● Remote debugging and fault diagnosis ● One key to contact customer service ● Check the help manual online |
Warranty
1 year's warranty with lifetime technical support.
