5V50mA 8 Channels Battery Testing Equipment for Coin Cell R&D

Name: 5V50mA 8 Channels Battery Testing Equipment for Coin Cell R&D
Brand: Shenzhen TICO Technology Co.,Ltd.
SKU: STC-4008Tn-5V50mA
Price: 2,900.00 USD
Availability: InStock

Brand Name:	TICO
Model Number:	STC-4008Tn-5V50mA
MOQ:	1 set
Price:	Negotiable
Delivery Time:	8~15 working days
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Shen Zhen

Model:

STC-4008Tn-5V50mA

Input Power:

25W

Resolution:

AD: 24bit; DA: 16bit

Input Resistance:

≥1GΩ

Dimension:

L443 * W330 * H48mm

Packaging Details:

Standard export packing

Supply Ability:

30 sets per month

Product Description

5V50mA 8 Channels Battery Testing Equipment for Coin Cell R&D

Brief Introduction

CT-4008Tn-5V50mA is 8 channels battery testing system used for coin cell testing from 5uA~50mA, up to 5V. It is three range, 5uA~1mA,1mA~25mA, 25mA~50mA.

The accuracy for current and voltage on these channels is ±0.05% FS. It has 8 channels, each channel is working independently. It is perfect for coin cell testing and widely used in university, lab, manufacturer sampling making.

Key Feature

● Multi ranges.

● Wide application .

● High accuracy, ±0.05% FS.

● Fast response time.

● Each channel is independent.

Technical Parameter

Input power		AC 220V ±10% / 50Hz
Resolution		AD: 24bit; DA: 16bit
Input resistance		≥ 1GΩ
Input power		25W
Channel features		Constant current source and constant voltage source with independent pairs of closed-loop structure
Channel control mode		Independent control
Voltage	Per channel control voltage range	25mV~5V
	Minimum discharge voltage	-5V
	Accuracy	± 0.05% of FS
	Stability	± 0.05% of FS
Current	Per channel current range	Range 1: 5μA~1mA Range 2: 1mA~25mA Range 3: 25mA~50mA
	Constant current cut-off current	Range 1: 2μA Range 2: 50μA Range 3: 100μA
	Accuracy	± 0.05% of FS
	Stability	± 0.05% of FS
Power	Per channel output power	0.25W
Power	Stability	± 0.1% of FS
Time	Current response time	< 500μs
Time	Step time range	≤ (365 * 24 )hour/step, Time form support 00: 00: 00.000 (h,min,s,ms)
Data recording	Record condition	Time△t: 100ms
		Voltage △U: 10mV
		Current△I: Range 1: 2μA Range 2: 50μA Range 3: 100μA
	Record frequency	10Hz
Charge	Charge mode	Constant current charge, constant voltage charge, constant current and constant voltage charge, constant power charge
Charge	End condition	Voltage, current, relative time, capacity, -△V
Discharge	Discharge mode	Constant current discharge, constant voltage discharge, constant current and constant voltage discharge, constant power discharge, constant resistance discharge
Discharge	End condition	Voltage, current, relative time, capacity, -△V
DCIR test supported
Pulse test	Charge	Constant current charge, constant power charge
	Discharge	Constant current discharge, constant power discharge
	Minimum pulse width	500ms
	Pulse number	32 different pulse for a single step
	Charge and discharge switch	Continuous switched for a single pulse step
	End condition	Voltage, relative time
Cycle	Loop measure range	1 ~ 65535 times
	Max steps per loop	254
	Nested loop	Nested loop function, max support 3 layers
Protection	Software protection	● Power-down data protection
		● Off-line testing function
		● Setting protection condition, setting parameter include low voltage limit, upper voltage limit, low current limit, upper current limit, delay time
	Hardware protection	Additional anti-reverse protection model
Voltage and current testing sample		4-wire connecting
Noise		< 45dB
Database		MySQL database
A means of communication of upper machine		TCP/IP protocol
Data output		EXCEL 2003,2010,TXT
Communication interface		Internet access
Server operating system		Windows 7
Leak current		0.005μA
Per unit main channels No.		8
Dimensions(WDH)(mm)		1U(164),443 * 330 * 48

Warranty

1 year warranty with lifetime support. Man-made damage is not covered.

FAQ

1. Are you a manufacturer?

A: Yes, our factory is located in Shenzhen, China.
We have more than 10 year experience for manufacturing battery lab research equipment. We own a professional R&D department.

2. Do you accept customized product?

A: Yes. Most of our products can be customized to meet different requirements.

3. Will you provide test video before dispatch?

A: Yes, we take test video for every equipment before dispatch, which will display how to use it.

4. Can you offer overseas installation service?

A: Yes, we can dispatch professional engineer for on-site installation service.
